Feel free to download our SPEC table for B&M EEPROM
<
| HK B&M Magnetic Hall Sensor IC SPEC Table | |||||
| <-Return | www.bm-cs.com | ||||
| Whatsapp/Wechat: +86-18621961382 Mail: sales@bm-cs.com or java.zhang@bm-cs.com | |||||
| PN | CELL | Package | VCC | Density(bit) | PinPos |
| SC24C02A | EEPROM | SOP8 150MIL | 1.8~5.5 | 2K | A0/A1/A2/GND/SDA/SCL/WP/VCC |
| SC24C04A | EEPROM | SOP8 150MIL | 1.8~5.5 | 4K | A0/A1/A2/GND/SDA/SCL/WP/VCC |
| SC24C08A | EEPROM | SOP8 150MIL | 1.8~5.5 | 8K | A0/A1/A2/GND/SDA/SCL/WP/VCC |
| SC24C16A | EEPROM | SOP8 150MIL | 1.8~5.5 | 16K | A0/A1/A2/GND/SDA/SCL/WP/VCC |
| SC24C32A | EEPROM | SOP8 150MIL | 1.8~5.5 | 32K | A0/A1/A2/GND/SDA/SCL/WP/VCC |
| SC24C64A | EEPROM | SOP8 150MIL | 1.8~5.5 | 64K | A0/A1/A2/GND/SDA/SCL/WP/VCC |
| SC24C128A | EEPROM | SOP8 150MIL | 1.8~5.5 | 128K | A0/A1/A2/GND/SDA/SCL/WP/VCC |
| SC24C256A | EEPROM | SOP8 150MIL | 1.8~5.5 | 256K | A0/A1/A2/GND/SDA/SCL/WP/VCC |
| SC25S40A | FLASH | SOP8 150MIL | 1.8~5.5 | 4M | CS/SO/WP/VSS/SI/SCLK/HOLD/VSS |
| SC25S80A | FLASH | SOP8 150MIL | 1.8~5.5 | 8M | CS/SO/WP/VSS/SI/SCLK/HOLD/VSS |
| SC25S80A | FLASH | SOP8 208 MIL | 1.8~5.5 | 8M | CS/SO/WP/VSS/SI/SCLK/HOLD/VSS |
| SC25S16A | FLASH | SOP8 150MIL | 1.8~5.5 | 16M | CS/SO/WP/VSS/SI/SCLK/HOLD/VSS |
| SC25S16A | FLASH | SOP8 208 MIL | 1.8~5.5 | 16M | CS/SO/WP/VSS/SI/SCLK/HOLD/VSS |
| SC25S32A | FLASH | SOP8 208MIL | 1.8~5.5 | 32M | CS/SO/WP/VSS/SI/SCLK/HOLD/VSS |
