Feel free to download our SPEC table for DCDC regulator
<
| HK B&M DCDC Regulator SPEC Table | |||||||||
| <-Return | www.bm-cs.com | ||||||||
| Whatsapp/Wechat: +86-18621961382 Mail: sales@bm-cs.com or java.zhang@bm-cs.com | |||||||||
| Type | Package | Type | Vin | Vout | Isw | VFB | Fsw&Mode | Frequency | PinPos |
| SC9451T6 | SOT-23-6L | BUCK | 4.5~36 | 0.5~Vin*Dmax | 1.5 | 0.9 | 150KHz@PWM | 0.97 | FB/G/IN/SW/BS/CS |
| SC9464S8 | SOP-8 | BUCK | 6.5~36 | 0.5~Vin*Dmax | 2.4 | 1.2 | 100KHz@PWM | 0.95 | BS/IN/SW/G/FB/IADJ/EN/SS |
| SC9465E8 | ESOP8 | BUCK | 6.5~36 | 0.5~Vin*Dmax | 2.5 | 0.8 | 100KHz@PWM | 0.95 | BS/IN/SW/GND/FB/COMP/EN/SS |
| SC9482E8 | ESOP8 | BUCK | 6.5~36 | 0.5~Vin*Dmax | 3.1 | 0.9 | 300KHz@PWM | 0.95 | BS/IN/SW/G/FB/NC/EN/SS |
| SC9484E8 | ESOP8 | BUCK | 6.5~36 | 0.5~Vin*Dmax | 3.1 | 1.2 | 100KHz@PWM | 0.96 | BS/IN/SW/GND/FB/IADJ/DP||DM/SS |
| SC9486E8 | ESOP8 | BUCK | 6.5~36 | 0.5~Vin*Dmax | 3.1 | 1.2 | 100KHz@PWM | 0.95 | BS/IN/SW/GND/FB/CS/DM/DP |
| SC9213T5 | SOT-23-5L | BUCK | 2.5~5.5 | 0.6~5.0 | 0.6 | 0.6 | 1.5MHz@PWM | 0.96 | IN/GND/CE/FB/SW |
| SC9311T6 | SOT-23-6L | BOOST | 0.9~5.5 | 2.5~5.5 | 1.1 | 1.23 | 1.2MHz@PWM | 0.95 | SW/GND/FB/SHDN/O/I |
| SC9460T6 | SOT-23-6L | BUCK | 4.5~18 | 0.6~7.0 | 2 | 0.6 | 500KHz@PWM/PSM | 0.95 | BS/GND/FB/EN/I/SW |
| SC9101T5 | SOT-23-5L | BOOST | 2.0~5.5 | Vin~28 | 0.4 | 0.8 | 1MHz@PWM | 0.88 | IN/EN/SW/GND/NC/FB |
| SC9215T5 | SOT-23-5L | BUCK | 2.0~6.5 | 0.6~5.0 | 0.8 | 0.6 | 1.5MHz@PWM/PSM | 0.96 | EN/GND/SW/IN/FB |
| SC9321T6 | SOT-23-6L | BOOST | 2.7~5.5 | 3.0~5.5 | 2.5 | 0.6 | 1.25MHz@PWM/PFM | 0.9 | SW/GND/FB/CE/IN/ILIMIT |
| SC9313T6 | SOT-23-6L | BOOST | 0.5~4.5 | 2.5~5.25 | 1.2 | 0.6 | 1.2MHz@PWM | 0.95 | SW/GND/FB/CE/O/IN |
| SC9107A**K | SOT-23 | BOOST | 0.9~6.0 | 2.1~5.5 | 1 | / | 300KHz@PFM | 0.95 | O/G/LX |
| SC9107B**T5 | SOT-23-5L | BOOST | 0.9~6.0 | 2.1~5.5 | 1 | / | 300KHz@PFM | 0.95 | EN/O/NC/G/LX |
| SC9107A**R | SOT-89-3L | BOOST | 0.9~6.0 | 2.1~5.5 | 1 | / | 300KHz@PFM | 0.95 | G/O/LX |
| SC9117A**R | SOT-89-3L | BOOST | 0.9~6.0 | 1.9~5.5 | 1 | / | 100KHz@PFM | 0.85 | G/O/LX |
| SC9117C**T5 | SOT-23-5L | BOOST | 0.9~6.0 | 1.9~5.5 | 1 | / | 100KHz@PFM | 0.85 | EN/O/NC/G/LX |
| SC9117A50T3 | SOT-23-3L | BOOST | 0.9~6.0 | 1.9~5.5 | 1 | / | 100KHz@PFM | 0.85 | O/G/LX |
| SC9340T6 | SOT-23-6L | BOOST | 2.0~24 | Vin~28 | 4 | 0.6 | 1.2MHz@PWM/PFM | 0.88 | SW/GND/FB/EN/IN/NC |
| SC9217T5 | SOT-23-5L | BUCK | 2.0~6.0 | 0.6~5.0 | 1.5 | 0.6 | 1.5MHz@PWM/PSM | 0.96 | EN/GND/SW/IN/FB |
| SC9212DN6 | DFN2×2-6L | BUCK | 2.6~6.0 | 0.6~5.0 | 1 | 0.6 | 1.5MHz@PWM/PSM | 0.96 | NC/EN/IN/SW/GND/FB |
| SC9140T6 | SOT-23-6L | BOOST | 2.7~6.0 | 40max | 1 | NA | 0.8MHz@PWM | 0.91 | SW/GND/FB/EN/NC/IN |
| SC9461M | SOT-563 | BUCK | 4.5~18 | 0.8~5.0 | 2 | 0.8 | 700KHz@COT | 0.95 | IN/SW/GND/BS/EN/FB |
| SC9463M | SOT-563 | BUCK | 4.5~18 | 0.8~5.0 | 3 | 0.8 | 700KHz@COT | 0.95 | IN/SW/GND/BS/EN/FB |
| SC9216T5 | SOT-23-5L | BUCK | 2.6~6.0 | 0.6~5.0 | 1 | 0.6 | 1.5MHz@PWM/PSM | 0.96 | EN/GND/SW/IN/FB |
| SC9219T5 | SOT-23-5L | BUCK | 2.6~6.0 | 0.6~5.0 | 2 | 0.6 | 3MHz@PWM/PSM | 0.96 | EN/GND/SW/IN/FB |
| SC9462T6 | SOT-23-6L | BUCK | 4.5~18 | 0.8~7.0 | 2 | 0.8 | 500KHz@PWM/PSM | 0.95 | GND/SW/IN/FB/EN/BS |
| SC9468T6 | SOT-23-6L | BUCK | 4.5~18 | 0.8~7.0 | 3 | 0.8 | 500KHz@PWM/PSM | 0.95 | GND/SW/IN/FB/EN/BS |
| SC9465T6 | SOT-23-6L | BUCK | 4.5~18 | 0.8~5.0 | 2 | 0.8 | 700KHz@PWM/PSM | 0.95 | GND/SW/IN/FB/EN/BS |
| SC9467T6 | SOT-23-6L | BUCK | 4.5~18 | 0.8~5.0 | 3 | 0.8 | 700KHz@PWM/PSM | 0.95 | GND/SW/IN/FB/EN/BS |
| SC9466S8 | SOP-8 | BUCK | 3.6~18 | 0.923~6.0 | 2 | NA | 340KHz@PWM/PSM | 0.9 | BS/IN/SW/GND/FB/COMP/EN/SS |
| SC9469E8 | ESOP8 | BUCK | 3.6~18 | 0.923~6.0 | 3 | NA | 340KHz@PWM/PSM | 0.95 | BS/IN/SW/GND/FB/COMP/EN/SS |
| SC9470E8 | ESOP8 | BUCK | 4.2~18 | 0.923~8.0 | 4 | NA | 340KHz@PWM/PSM | 0.95 | BS/IN/SW/GND/FB/COMP/EN/SS |
