Branded LDO, DCDC chips
Feel free to download our SPEC table for branded LDO,DCDC chips
Feel free to download our SPEC table for branded LDO,DCDC chips
<
| HK B&M Low Drop Regulator SPEC Table | |||||||||
| <-Return | www.bm-cs.com | ||||||||
| Whatsapp/Wechat: +86-18621961382 Mail: sales@bm-cs.com or java.zhang@bm-cs.com | |||||||||
| Type | Package | Type | Vin | Vout | Isw | VFB | Fsw&Mode | Frequency | PinPos |
| SC9451T6 | SOT-23-6L | BUCK | 4.5~36 | 0.5~Vin*Dmax | 1.5 | 0.9 | 150KHz@PWM | 0.97 | FB/G/IN/SW/BS/CS |
| SC9464S8 | SOP-8 | BUCK | 6.5~36 | 0.5~Vin*Dmax | 2.4 | 1.2 | 100KHz@PWM | 0.95 | BS/IN/SW/G/FB/IADJ/EN/SS |
| SC9465E8 | ESOP8 | BUCK | 6.5~36 | 0.5~Vin*Dmax | 2.5 | 0.8 | 100KHz@PWM | 0.95 | BS/IN/SW/GND/FB/COMP/EN/SS |
| SC9482E8 | ESOP8 | BUCK | 6.5~36 | 0.5~Vin*Dmax | 3.1 | 0.9 | 300KHz@PWM | 0.95 | BS/IN/SW/G/FB/NC/EN/SS |
| SC9484E8 | ESOP8 | BUCK | 6.5~36 | 0.5~Vin*Dmax | 3.1 | 1.2 | 100KHz@PWM | 0.96 | BS/IN/SW/GND/FB/IADJ/DP||DM/SS |
| SC9486E8 | ESOP8 | BUCK | 6.5~36 | 0.5~Vin*Dmax | 3.1 | 1.2 | 100KHz@PWM | 0.95 | BS/IN/SW/GND/FB/CS/DM/DP |
| SC9213T5 | SOT-23-5L | BUCK | 2.5~5.5 | 0.6~5.0 | 0.6 | 0.6 | 1.5MHz@PWM | 0.96 | IN/GND/CE/FB/SW |
| SC9311T6 | SOT-23-6L | BOOST | 0.9~5.5 | 2.5~5.5 | 1.1 | 1.23 | 1.2MHz@PWM | 0.95 | SW/GND/FB/SHDN/O/I |
| SC9460T6 | SOT-23-6L | BUCK | 4.5~18 | 0.6~7.0 | 2 | 0.6 | 500KHz@PWM/PSM | 0.95 | BS/GND/FB/EN/I/SW |
| SC9101T5 | SOT-23-5L | BOOST | 2.0~5.5 | Vin~28 | 0.4 | 0.8 | 1MHz@PWM | 0.88 | IN/EN/SW/GND/NC/FB |
| SC9215T5 | SOT-23-5L | BUCK | 2.0~6.5 | 0.6~5.0 | 0.8 | 0.6 | 1.5MHz@PWM/PSM | 0.96 | EN/GND/SW/IN/FB |
| SC9321T6 | SOT-23-6L | BOOST | 2.7~5.5 | 3.0~5.5 | 2.5 | 0.6 | 1.25MHz@PWM/PFM | 0.9 | SW/GND/FB/CE/IN/ILIMIT |
| SC9313T6 | SOT-23-6L | BOOST | 0.5~4.5 | 2.5~5.25 | 1.2 | 0.6 | 1.2MHz@PWM | 0.95 | SW/GND/FB/CE/O/IN |
| SC9107A**K | SOT-23 | BOOST | 0.9~6.0 | 2.1~5.5 | 1 | / | 300KHz@PFM | 0.95 | O/G/LX |
| SC9107B**T5 | SOT-23-5L | BOOST | 0.9~6.0 | 2.1~5.5 | 1 | / | 300KHz@PFM | 0.95 | EN/O/NC/G/LX |
| SC9107A**R | SOT-89-3L | BOOST | 0.9~6.0 | 2.1~5.5 | 1 | / | 300KHz@PFM | 0.95 | G/O/LX |
| SC9117A**R | SOT-89-3L | BOOST | 0.9~6.0 | 1.9~5.5 | 1 | / | 100KHz@PFM | 0.85 | G/O/LX |
| SC9117C**T5 | SOT-23-5L | BOOST | 0.9~6.0 | 1.9~5.5 | 1 | / | 100KHz@PFM | 0.85 | EN/O/NC/G/LX |
| SC9117A50T3 | SOT-23-3L | BOOST | 0.9~6.0 | 1.9~5.5 | 1 | / | 100KHz@PFM | 0.85 | O/G/LX |
| SC9340T6 | SOT-23-6L | BOOST | 2.0~24 | Vin~28 | 4 | 0.6 | 1.2MHz@PWM/PFM | 0.88 | SW/GND/FB/EN/IN/NC |
| SC9217T5 | SOT-23-5L | BUCK | 2.0~6.0 | 0.6~5.0 | 1.5 | 0.6 | 1.5MHz@PWM/PSM | 0.96 | EN/GND/SW/IN/FB |
| SC9212DN6 | DFN2×2-6L | BUCK | 2.6~6.0 | 0.6~5.0 | 1 | 0.6 | 1.5MHz@PWM/PSM | 0.96 | NC/EN/IN/SW/GND/FB |
| SC9140T6 | SOT-23-6L | BOOST | 2.7~6.0 | 40max | 1 | NA | 0.8MHz@PWM | 0.91 | SW/GND/FB/EN/NC/IN |
| SC9461M | SOT-563 | BUCK | 4.5~18 | 0.8~5.0 | 2 | 0.8 | 700KHz@COT | 0.95 | IN/SW/GND/BS/EN/FB |
| SC9463M | SOT-563 | BUCK | 4.5~18 | 0.8~5.0 | 3 | 0.8 | 700KHz@COT | 0.95 | IN/SW/GND/BS/EN/FB |
| SC9216T5 | SOT-23-5L | BUCK | 2.6~6.0 | 0.6~5.0 | 1 | 0.6 | 1.5MHz@PWM/PSM | 0.96 | EN/GND/SW/IN/FB |
| SC9219T5 | SOT-23-5L | BUCK | 2.6~6.0 | 0.6~5.0 | 2 | 0.6 | 3MHz@PWM/PSM | 0.96 | EN/GND/SW/IN/FB |
| SC9462T6 | SOT-23-6L | BUCK | 4.5~18 | 0.8~7.0 | 2 | 0.8 | 500KHz@PWM/PSM | 0.95 | GND/SW/IN/FB/EN/BS |
| SC9468T6 | SOT-23-6L | BUCK | 4.5~18 | 0.8~7.0 | 3 | 0.8 | 500KHz@PWM/PSM | 0.95 | GND/SW/IN/FB/EN/BS |
| SC9465T6 | SOT-23-6L | BUCK | 4.5~18 | 0.8~5.0 | 2 | 0.8 | 700KHz@PWM/PSM | 0.95 | GND/SW/IN/FB/EN/BS |
| SC9467T6 | SOT-23-6L | BUCK | 4.5~18 | 0.8~5.0 | 3 | 0.8 | 700KHz@PWM/PSM | 0.95 | GND/SW/IN/FB/EN/BS |
| SC9466S8 | SOP-8 | BUCK | 3.6~18 | 0.923~6.0 | 2 | NA | 340KHz@PWM/PSM | 0.9 | BS/IN/SW/GND/FB/COMP/EN/SS |
| SC9469E8 | ESOP8 | BUCK | 3.6~18 | 0.923~6.0 | 3 | NA | 340KHz@PWM/PSM | 0.95 | BS/IN/SW/GND/FB/COMP/EN/SS |
| SC9470E8 | ESOP8 | BUCK | 4.2~18 | 0.923~8.0 | 4 | NA | 340KHz@PWM/PSM | 0.95 | BS/IN/SW/GND/FB/COMP/EN/SS |
<
| HK B&M Low Drop Regulator SPEC Table | |||||||||||
| <-Return | www.bm-cs.com | ||||||||||
| Whatsapp/Wechat: +86-18621961382 Mail: sales@bm-cs.com or java.zhang@bm-cs.com | |||||||||||
| Type | Package | Vin | Vout | Iout(mA) | Iq(uA) | Vdrop(mV) | PSRR@1KHz(dB) | Precision(%) | Vout Alternatives | Feature | PinPos |
| SC6204A**M | SOT-23-3L | 2~6 | 1~5 | 300 | 50 | 150 | 75 | 1、2 | 1.2,1.8,2.8,3.3 | High PSRR | GOI |
| SC6204B**F | WBFBP-04C | 2~6 | 1~5 | 300 | 50 | 150 | 75 | 1、2 | 1.8,2.8 | High PSRR | OGEI |
| SC6204B**F | DFN1*1-4L | 2~6 | 1~5 | 300 | 50 | 150 | 75 | 1、2 | 1.8,2.8 | High PSRR | OGEI |
| SC6204B**M | SOT-23-5L | 2~6 | 1~5 | 300 | 50 | 150 | 75 | 1、2 | 1.2,1.8,2.8,3.3 | High PSRR | IGENO |
| SCB6204B**M | SOT-23-5L | 2~6 | 1.2~5 | 250 | 50 | 150 | 70 | 1、2 | 1.2,1.5,1.8,2.5,2.8,3.0,3.3 | Low Consumption | IGENO |
| SC6205A**M | SOT-23-3L | 2~6 | 1~5 | 500 | 50 | 150 | 75 | 1、2 | 1.2,1.8,2.8,3.3 | High PSRR | GOI |
| SC6205B**F | WBFBP-04C | 2~6 | 1~5 | 500 | 50 | 150 | 75 | 1、2 | 1.8,2.8 | High PSRR | OGEI |
| SC6205B**F | DFN1*1-4L | 2~6 | 1~5 | 500 | 50 | 150 | 75 | 1、2 | 1.8,2.8 | High PSRR | OGEI |
| SC6205B**M | SOT-23-5L | 2~6 | 1~5 | 500 | 50 | 150 | 75 | 1、2 | 1.2,1.8,2.5,2.8,3.3 | High PSRR | IGENO |
| SC6205B**U | SOT-353 | 2~6 | 1~5 | 500 | 50 | 150 | 75 | 1、2 | 1.2,1.8,2.5,2.8,3.3 | High PSRR | IGENO |
| SC6225A**M | SOT-23-3L | 2~6 | 1~5 | 500 | 50 | 50 | 80 | 1、2 | 1.8,3.3 | High PSRR | GOI |
| SC6225B**F | WBFBP-04C | 2~6 | 1~5 | 500 | 50 | 50 | 80 | 1、2 | 1.8,3.3 | High PSRR | OGEI |
| SC6225B**F | DFN1*1-4L | 2~6 | 1~5 | 500 | 50 | 50 | 80 | 1、2 | 1.8,3.3 | High PSRR | OGEI |
| SC6225B**M | SOT-23-5L | 2~6 | 1~5 | 500 | 50 | 50 | 80 | 1、2 | 1.8,3.3 | High PSRR | IGENO |
| SCB6205B**M | SOT-23-5L | 2~6 | 1~5 | 400 | 50 | 150 | 70 | 1、2 | 1.2,1.5,1.8,2.5,2.8,3.0,3.3 | Low Consumption | IGENO |
| SC6107A**P | SOT-89-3L | 2.5-6 | 1.5-5 | 1000 | 70 | 150 | 70 | 2 | 3.3 | Load up to 1A，High PSRR | GIO |
| SC6107B**P | SOT-89-5L | 2.5-6 | 1.5-5 | 1000 | 70 | 150 | 70 | 2 | 3.3 | Load up to 1A，High PSRR | E/G/N/I/O |
| SC6210A**G | SOT-223 | 2~6 | 1.5~5 | 1500 | 50 | 60 | 70 | 2 | 3.3,5.0 | High Power，Load up to 1.5A | GIO |
| SC6211EEjtE | SOT-23-6L | 2~6 | 1~5 | 500 | 50 | 150 | 70 | 1、2 | 1.8+3.3 | Double Channel LDO | E1/I/E2/O2/G/O1 |
| SC6230A**M | SOT-23-3L | 2~7 | 1.2~5 | 300 | 5 | 150 | 70 | 2 | 1.2,1.8,2.8,3.0,3.3,3.6 | Low Quiescent Current | GOI |
| SC6230B**F | WBFBP-04C | 2~7 | 1.2~5 | 300 | 5 | 150 | 70 | 2 | 1.2,1.5,2.5,3.0,3.3 | Low Quiescent Current | OGEI |
| SC6230B**F | DFN1*1-4L | 2~7 | 1.2~5 | 300 | 5 | 150 | 70 | 2 | 1.2,1.5,2.5,3.0,3.3 | Low Quiescent Current | OGEI |
| SC6230B**M | SOT-23-5L | 2~7 | 1.2~5 | 300 | 5 | 150 | 70 | 2 | 1.2,1.8,2.8,3.0,3.3,3.6 | Low Quiescent Current | IGENO |
| SC6230A**P | SOT-89-3L | 2~7 | 1.2~5 | 300 | 5 | 150 | 70 | 2 | 3.6 | Low Quiescent Current | GIO |
| SCB6230A**M | SOT-23 | 2~6 | 1.2~5 | 300 | 3 | 280 | 50 | 2 | 1.2,1.5,1.8,2.5,2.8,3.0,3.3 | Low Quiescent Current | GOI |
| SCB6230A**M | SOT-23-3L | 2~6 | 1.2~5 | 300 | 3 | 280 | 50 | 2 | 1.2,1.5,1.8,2.5,2.8,3.0,3.3 | Low Quiescent Current | GOI |
| SC6232A**M | SOT-23-3L | 1.8~8 | 1.2~5 | 300 | 0.8 | 110 | 50 | 1、2 | 1.2,2.8,3.3 | Super Low Quiescent Current | GOI |
| SC6232B**M | SOT-23-5L | 1.8~8 | 1.2~5 | 300 | 0.8 | 110 | 50 | 1、2 | 1.2,2.8,3.3 | Super Low Quiescent Current | IGENO |
| SC6232B**F | WBFBP-04C | 1.8~8 | 1.2~5 | 300 | 0.8 | 110 | 50 | 1、2 | 2.8,3.3 | Super Low Quiescent Current | OGEI |
| SC6232B**F | DFN1*1-4L | 1.8~8 | 1.2~5 | 300 | 0.8 | 110 | 50 | 1、2 | 1.8,2.8,3.3 | Super Low Quiescent Current | OGEI |
| SC6260A**P | SOT-89-3L | 2~6 | 0.9~5 | 500 | 6 | 120 | 60 | 2 | 3.3 | Low Quiescent Current | GIO |
| SC6300SC | SOT-23-5L | 1.8~7.0 | 0.6~5.4 | 500 | 45 | 110 | 70 | 1、2 | By User | Adjustable output | IGEFO |
| SC6300BE | SOT-23-6L | 1.8~7.0 | 0.6~5.4 | 500 | 45 | 110 | 70 | 1、2 | By User | Adjustable output | IGENFO |
| SC6300BN | WBHFBP-06L | 1.8~7.0 | 0.6~5.4 | 500 | 45 | 110 | 70 | 1、2 | By User | Adjustable output | EGIONF |
| SCB6330A**M | SOT-23 | 3~15 | 1.8~5 | 350 | 1 | 250 | 50 | 2 | 2.8,3.0,3.3,3.6,5.0 | Low Quiescent Current & Vin up to 18V | GOI |
| SCB6330A**M | SOT-23-3L | 3~15 | 1.8~5 | 350 | 1 | 250 | 51 | 2 | 2.8,3.0,3.3,3.6,5.0 | Low Quiescent Current & Vin up to 18V | GOI |
| SCB6330B**M | SOT-23-5L | 3~15 | 1.8~5 | 350 | 1 | 250 | 52 | 2 | 1.8,3.3,5.0 | Low Quiescent Current & Vin up to 18V | IGENO |
| SC6330A**M | SOT-23-3L | 2.5~18 | 1.2~5 | 300 | 2 | 160 | 65 | 1、2 | 1.8,3.3,3.6,5.0 | Low Quiescent Current & Vin up to 18V | GOI |
| SC6330B**M | SOT-23-5L | 2.5~18 | 1.2~5 | 300 | 2 | 160 | 65 | 1、2 | 2.8,3.0,3.3,5.0 | Low Quiescent Current & Vin up to 18V | IGENO |
| SC6330B**MR | SOT-23-5L | 2.5~18 | 1.2~5 | 300 | 2 | 160 | 65 | 1、2 | 2.8,3.3,5.0 | Low Quiescent Current & Vin up to 18V | GIOEN |
| SC6330A**P | SOT-89-3L | 2.5~18 | 1.2~5 | 300 | 2 | 160 | 65 | 1、2 | 1.8,3.3,3.6,5.0 | Low Quiescent Current & Vin up to 18V | GIO |
| SC6330A**T | TO-92 | 2.5~18 | 1.2~5 | 300 | 2 | 160 | 65 | 1、2 | 3.0,,3.3 | Low Quiescent Current & Vin up to 18V | GIO |
| SC6375A**M | SOT-23-3L | 2.5~36 | 2.1~12 | 250 | 2 | 400 | 70 | 1、2 | 3.3,5.0 | Low Quiescent Current & Vin up to 36V | GOI |
| SC6375A**MR | SOT-23-5L | 2.5~36 | 2.1~12 | 250 | 2 | 400 | 70 | 1、2 | 3.3,5.0 | Low Quiescent Current & Vin up to 36V | GIONN |
| SC6375A**MF | SOT-23-5L | 2.5~36 | 2.1~12 | 250 | 2 | 400 | 70 | 1、2 | 3.3,5.0 | Low Quiescent Current & Vin up to 36V | IGNNO |
| SC6375A**T | TO-92 | 2.5~36 | 2.1~12 | 250 | 2 | 400 | 70 | 1、2 | 5 | Low Quiescent Current & Vin up to 36V | GIO |
| SC75** | SOT-89-3L | 2.5~36 | 2.1~12 | 250 | 2 | 400 | 71 | 1、2 | 3.3,3.6,5.0,12 | Low Quiescent Current & Vin up to 36V | GIO |
| SC75L05 | SOT-89-3L | 2.5~36 | 5±0.1 | 100 | 2 | 500 | 72 | 2 | 3.3,5.0,12 | Low Quiescent Current & Vin up to 36V | OGI |
| SC6386A**M | SOT-23-3L | 2.5~45 | 2.1~12 | 100 | 2 | 600 | 73 | 2 | 3.3 | Low Quiescent Current & Vin up to 45V | GOI |
| SC86L05 | SOT-89-3L | 2.5~45 | 5±0.1 | 100 | 2 | 600 | 74 | 2 | 5 | Low Quiescent Current & Vin up to 45V | OGI |
| SC86XX | SOT-89-3L | 2.5~45 | 2.1~12 | 100 | 2 | 600 | 75 | 2 | 5 | Low Quiescent Current & Vin up to 45V | GIO |
| SC6386AM | SOT-23-3L | 2.5~45 | 2.1~12 | 100 | 2 | 600 | 70 | 2 | 3.3 | Low Quiescent Current & Vin up to 45V | GOI |
<
| brand | PN | package | MOQ | Vol | Conf | num | PSRR | Drop |
| HOLTEK | HT7125-1 | SOT-23-5 | 3000 | 2.5V | Positive | 1 | - | 100mV |
| HOLTEK | HT7125-1 | TO-92-3 | 1000 | 2.5V | Positive | 1 | - | 100mV |
| HOLTEK | HT7125-1 | SOT-89-3 | 1000 | 2.5V | Positive | 1 | - | 100mV |
| HOLTEK | HT7130-1 | SOT-89-3 | 1000 | 3.0V | Positive | 1 | - | 100mV |
| HOLTEK | HT7130-1 | SOT-23-5 | 3000 | 3.0V | Positive | 1 | - | 100mV |
| HOLTEK | HT7133-1 | SOT-89-3 | 1000 | 3.3V | Positive | 1 | - | 55mV |
| HOLTEK | HT7133-1 | SOT-23-5 | 3000 | 3.3V | Positive | 1 | - | 55mV |
| HOLTEK | HT7133-1 | TO-92-3 | 1000 | 3.3V | Positive | 1 | - | 55mV |
| HOLTEK | HT7150-1 | SOT-89-3 | 1000 | 5.0V | Positive | 1 | - | 55mV |
| HOLTEK | HT7150-1 | SOT-23-5 | 3000 | 5.0V | Positive | 1 | - | 55mV |
| HOLTEK | HT7150-1 | TO-92-3 | 1000 | 5.0V | Positive | 1 | - | 55mV |
| HOLTEK | HT7150-2 | SOT23-5 | 3000 | 5.0V | Positive | 1 | - | 55mV |
| HOLTEK | HT7150-2 | SOT-89-3 | 1000 | 5.0V | Positive | 1 | - | 55mV |
| HOLTEK | HT7230 | SOT23-5 | 3000 | 3.0V | Positive | 1 | - | 300mV |
| HOLTEK | HT7230 | SOT23-3 | 3000 | 3.0V | Positive | 1 | - | 300mV |
| HOLTEK | HT7230 | SOT-89-3 | 1000 | 3.0V | Positive | 1 | - | 300mV |
| HOLTEK | HT7233 | SOT-23-5 | 3000 | 3.3V | Positive | 1 | - | 300mV |
| HOLTEK | HT7233 | SOT23-3 | 3000 | 3.3V | Positive | 1 | - | 300mV |
| HOLTEK | HT7250 | SOT23-3 | 3000 | 5.0V | Positive | 1 | - | 300mV |
| HOLTEK | HT7250 | SOT23-5 | 3000 | 5.0V | Positive | 1 | - | 300mV |
| HOLTEK | HT7250 | SOT-89 | 1000 | 5.0V | Positive | 1 | - | 300mV |
| HOLTEK | HT7330-A | SOT-89-3 | 1000 | 3.0V | Positive | 1 | - | 95mV |
| HOLTEK | HT7330-A | TO-92-3 | 1000 | 3.0V | Positive | 1 | - | 95mV |
| HOLTEK | HT7333-1 | SOT-89-3 | 1000 | 3.3V | Positive | 1 | - | 300mV |
| HOLTEK | HT7333-3 | SOT-89-3 | 1000 | 3.3V | Positive | 1 | - | 300mV |
| HOLTEK | HT7333-A | SOT-89-3 | 1000 | 3.3V | Positive | 1 | - | 90mV |
| HOLTEK | HT7333-A | TO-92-3 | 1000 | 3.3V | Positive | 1 | - | - |
| HOLTEK | HT7350-A | SOT-89-3 | 1000 | 5.0V | Positive | 1 | - | 60mV |
| HOLTEK | HT7350-A | TO-92-3 | 1000 | 5.0V | Positive | 1 | - | - |
| HOLTEK | HT7530-1 | SOT-89-3 | 1000 | 3.0V | Positive | 1 | - | 100mV |
| HOLTEK | HT7530-1 | SOT-23-5 | 3000 | 3.0V | Positive | 1 | - | 100mV |
| HOLTEK | HT7530-1 | TO-92-3 | 1000 | 3.0V | Positive | 1 | - | 100mV |
| HOLTEK | HT7530-2 | SOT-23-5 | 3000 | 3.0V | Positive | 1 | - | 100mV |
| HOLTEK | HT7530-2 | SOT-89-3 | 1000 | 3.0V | Positive | 1 | - | 100mV |
| HOLTEK | HT7533-1 | SOT-89-3 | 1000 | 3.3V | Positive | 1 | - | 55mV |
| HOLTEK | HT7533-1 | SOT-23-5 | 3000 | 3.3V | Positive | 1 | - | 55mV |
| HOLTEK | HT7533-1 | TO-92-3 | 1000 | 3.3V | Positive | 1 | - | 55mV |
| HOLTEK | HT7533-2 | SOT-89-3 | 1000 | 3.3V | Positive | 1 | - | 55mV |
| HOLTEK | HT7533-2 | SOT-23-5 | 3000 | 3.3V | Positive | 1 | - | 55mV |
| HOLTEK | HT7533-3 | SOT-89-3 | 1000 | 3.3V | Positive | 1 | - | 55mV |
| HOLTEK | HT7550-1 | SOT-89-3 | 1000 | 5.0V | Positive | 1 | - | 55mV |
| HOLTEK | HT7550-1 | TO-92-3 | 1000 | 5.0V | Positive | 1 | - | 55mV |
| HOLTEK | HT7550-2 | SOT-89-3 | 1000 | 5.0V | Positive | 1 | - | 55mV |
| HOLTEK | HT7550-2 | SOT-23-5 | 3000 | 5.0V | Positive | 1 | - | 55mV |
| HOLTEK | HT7590-1 | SOT-23-5 | 3000 | 9.0V | Positive | 1 | - | 55mV |
| HOLTEK | HT7590-1 | SOT-89-3 | 1000 | 9.0V | Positive | 1 | - | 55mV |
| Onsemi | CAT6219-330TDGT3 | TSOT-23-5 | 3000 | Fixed | Positive | 1 | 64dB | 500mV |
| Onsemi | CS8182YDFR8G | SOIC-8 | 2500 | Adjustable | Positive | 1 | 60dB(120Hz) | 600mV |
| Onsemi | LM2931AD-5.0R2G | SOIC-8 | 2500 | 5.0V | Positive | 1 | 90dB(120Hz) | 600mV |
| Onsemi | LM2931AZ-5.0RAG | TO-92-3 | 2000 | 5.0V | Positive | 1 | 90dB(120Hz) | 600mV |
| Onsemi | LM2931CDR2G | SOIC-8_150mil | 2500 | Adjustable | Positive | 1 | - | 600mV |
| Onsemi | LP2950ACDT-5RKG | TO-252-2 | 2500 | 5.0V | Positive | 1 | - | 450mV |
| Onsemi | LP2950CDT-3.3RKG | TO-252-2 | 2500 | 3.3V | Positive | 1 | - | 450mV |
| Onsemi | MC33269DTRK-3.3G | DPAK | 2500 | 3.3V | Positive | 1 | 55dB(120Hz) | 1.35V |
| Onsemi | MC78M05CDTRKG | TO-252-2 | 2500 | 5.0V | Positive | 1 | 80dB(120Hz) | - |
| Onsemi | MC78M08CDTRKG | TO-252-2 | 2500 | 5.0V | Positive | 1 | 80dB(120Hz) | - |
| Onsemi | NCP1117DT33RKG | TO-252-2 | 2500 | 3.3V | Positive | 1 | 64dB(120Hz) | 1.2V |
| Onsemi | NCP1117DT33T5G | TO-252-2 | 2500 | 3.3V | Positive | 1 | 64dB(120Hz) | 1.2V |
| Onsemi | NCP1117DT50RKG | TO-252-2 | 2500 | 5.0V | Positive | 1 | 61dB(120Hz) | 1.2V |
| Onsemi | NCP1117DTARKG | TO-252-2 | 2500 | Adjustable | Positive | 1 | 73dB(120Hz) | 1.2V |
| Onsemi | NCP1117LPST33T3G | SOT-223 | 4000 | 3.3V | Positive | 1 | 60dB(120Hz) | 1.4V |
| Onsemi | NCP1117LPST50T3G | SOT-223 | 4000 | 5.0V | Positive | 1 | 60dB(120Hz) | 1.4V |
| Onsemi | NCP1117ST12T3G | SOT-223 | 4000 | 1.2V | Positive | 1 | 54dB(120Hz) | 1.2V |
| Onsemi | NCP1117ST18T3G | SOT-223 | 4000 | 1.8V | Positive | 1 | 70dB(120Hz) | 1.2V |
| Onsemi | NCP1117ST33T3G | SOT-223 | 4000 | 3.3V | Positive | 1 | 64dB(120Hz) | 1.2V |
| Onsemi | NCP1117ST50T3G | SOT-223 | 4000 | 5.0V | Positive | 1 | 61dB(120Hz) | 1.2V |
| Onsemi | NCP1117STAT3G | SOT-223 | 4000 | Adjustable | Positive | 1 | 73dB(120Hz) | 1.2V |
| Onsemi | NCP3334DADJR2G | SOIC-8 | 2500 | Adjustable | Positive | 1 | - | 340mV |
| Onsemi | NCP500SN18T1G | TSOT-23-5 | 3000 | 1.8V | Positive | 1 | 62dB(1kHz) | 350mV |
| Onsemi | NCP500SN33T1G | TSOP-5 | 3000 | 3.3V | Positive | 1 | 62dB(1kHz) | 230mV |
| Onsemi | NCP551SN33T1G | SOT-23-5 | 3000 | 3.3V | Positive | 1 | - | 150mV |
| Onsemi | NCP551SN50T1G | TSOP-5 | 3000 | 5.0V | Positive | 1 | - | 150mV |
| Onsemi | NCP553SQ33T1G | SC-70-4 | 3000 | 3.3V | Positive | 1 | - | 1V |
| Onsemi | NCP600SNADJT1G | SOT-23-5 | 3000 | Adjustable | Positive | 1 | 62dB | 125mV |
| Onsemi | NCP603SN330T1G | TSOP-5 | 3000 | 3.3V | Positive | 1 | 62dB | 230mV |
| Onsemi | NCP716MTG50TBG | WDFN-6 | 3000 | 5.0V | Positive | 1 | 54dB(100kHz) | 500mV |
| Onsemi | NCV1117DT33T5G | TO-252-2 | 2500 | 3.3V | Positive | 1 | 64dB(120Hz) | 1.2V |
| Onsemi | NCV1117ST33T3G | SOT-223 | 4000 | 3.3V | Positive | 1 | 64dB(120Hz) | 1.2V |
| Onsemi | NCV1117ST50T3G | SOT-223 | 4000 | 3.3V | Positive | 1 | 61dB(120Hz) | 1.2V |
| Onsemi | NCV4264-2ST50T3G | SOT-223 | 4000 | 5.0V | Positive | 1 | 67dB(100Hz) | 500mV |
| Onsemi | NCV4949ADR2G | SOIC-8 | 2500 | 5.0V | Positive | 1 | - | 500mV |
| Onsemi | NCV8184DR2G | SOIC-8 | 3000 | Adjustable | Positive | 1 | 60dB(120Hz) | 600mV |
| Onsemi | NCV8664ST50T3G | SOT-223-3 | 4000 | Fixed | Positive | 1 | 67dB(100Hz) | 600mV |
| TI | LM317LIPK | SOT-89-3 | 1000 | Adjustable | Positive | 1 | 80dB | - |
| TI | LM340MP-5.0 | SOT-223 | 1000 | 5.0V | Positive | 1 | 70dB(120Hz) | 2V |
| TI | LP2981-33DBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 63dB(1kHz) | 375mV |
| TI | LP2985-33DBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 45dB(1kHz) | 575mV |
| TI | LP2985-33DBVT | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 45dB(1kHz) | 580mV |
| TI | LP2985A-33DBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 45dB(1kHz) | 575mV |
| TI | LP2985A-50DBVR | SOT-23-5 | 3000 | 5.0V | Positive | 1 | 45dB(1kHz) | 580mV |
| TI | LP5907QMFX-3.0Q1 | SOT-23-5 | 3000 | 3.0v | Positive | 1 | 90dB | 250mV |
| TI | REG1117-3.3 | SOT-223 | 80 | 3.3V | Positive | 1 | 62dB(120Hz) | 1.2V |
| TI | TLV1117-33IDCYR | SOT-223 | 2500 | 3.3V | Positive | 1 | 75dB(120Hz) | 1.3V |
| TI | TLV1117CDCYR | SOT-223 | 2500 | Adjustable | Positive | 1 | 75dB(120Hz) | 1.3V |
| TI | TLV1117LV12DCYR | SOT-223 | 2500 | 1.2V | Positive | 1 | 75dB(120Hz) | 800mV |
| TI | TLV1117LV18DCYR | SOT-223 | 2500 | 1.8V | Positive | 1 | 65dB(100Hz) | 800mV |
| TI | TLV1117LV33DCYR | SOT-223 | 2500 | 3.3V | Positive | 1 | 75dB(120Hz) | 1.3V |
| TI | TLV70012DDCR | SOT-23-5 | 3000 | 1.2V | Positive | 1 | 68dB(1kHz) | 250mV |
| TI | TLV70018DCKR | SOT-353 | 3000 | 1.8V | Positive | 1 | 68dB(1kHz) | 250mV |
| TI | TLV70018DDCR | SOT-23-5 | 3000 | 1.8V | Positive | 1 | 68dB(1kHz) | 250mV |
| TI | TLV70025DDCR | SOT-23-5 | 3000 | 2.5V | Positive | 1 | 68dB(1kHz) | 250mV |
| TI | TLV70030DDCR | SOT-23-5 | 3000 | 3.0V | Positive | 1 | 68dB(1kHz) | 250mV |
| TI | TLV70033DCKR | SC-70-5 | 3000 | 3.3V | Positive | 1 | 68dB(1kHz) | 250mV |
| TI | TLV70033DDCR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 68dB(1kHz) | 250mV |
| TI | TLV70212DBVR | SOT-23-5 | 3000 | 1.2V | Positive | 1 | 68dB(1kHz) | 380mV |
| TI | TLV70218DBVR | SOT-23-5 | 3000 | 1.8V | Positive | 1 | 68dB(1kHz) | 375mV |
| TI | TLV70228DBVR | SOT-23-5 | 3000 | 2.8V | Positive | 1 | 68dB(1kHz) | 380mV |
| TI | TLV70233DBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 68dB(1kHz) | 375mV |
| TI | TLV70430DBVR | SOT-23-5 | 3000 | 3.0V | Positive | 1 | 60dB(100kHz) | 1.1V |
| TI | TLV70433DBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 60dB(100kHz) | 1.1V |
| TI | TLV70450DBVR | SOT-23-5 | 3000 | 5.0V | Positive | 1 | 60dB(100kHz) | 1.1V |
| TI | TLV71333PDBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 70dB | 540mV |
| TI | TLV73333PDBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 68dB | 270mV |
| TI | TPS70930DBVR | SOT-23-5 | 3000 | 3.0V | Positive | 1 | 80dB | 1.4V |
| TI | TPS70933DBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 80dB | 1.4V |
| TI | TPS70933DRVR | WSON-6 | 3000 | 3.3V | Positive | 1 | 80dB | 1.4V |
| TI | TPS70950DBVR | SOT-23-5 | 3000 | 5.0V | Positive | 1 | 80dB | 1.2V |
| TI | TPS71533DCKR | SC-70-5 | 3000 | 3.3V | Positive | 1 | 60dB(100kHz) | 750mV |
| TI | TPS71733DCKR | SC-70-5 | 3000 | 3.3V | Positive | 1 | 70dB | 300mV |
| TI | TPS73001DBVR | SOT-23-6 | 3000 | Adjustable | Positive | 1 | 68dB(100Hz) | 210mV |
| TI | TPS73033DBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 68dB(100Hz) | 210mV |
| TI | TPS73201DBVR | SOT-23-5 | 3000 | Adjustable | Positive | 1 | 58dB | 150mV |
| TI | TPS73533DRBR | SON-8 | 3000 | 3.3V | Positive | 1 | 66dB | 500mV |
| TI | TPS73601DBVR | SOT-23-5 | 3000 | Adjustable | Positive | 1 | 58dB | 200mV |
| TI | TPS73633DBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 58dB | 200mV |
| TI | TPS73733DCQR | SOT-223-6 | 2500 | 3.3V | Positive | 1 | 58dB | 500mV |
| TI | TPS73801DCQR | SOT-223-6 | 2500 | Adjustable | Positive | 1 | 58dB | 500mV |
| TI | TPS74701DRCR | VSON-10 | 3000 | Adjustable | Positive | 1 | 60dB | 120mV |
| TI | TPS74801DRCR | VSON-10 | 3000 | Adjustable | Positive | 1 | 50dB | 165mV |
| TI | TPS76318DBVR | SOT-23-5 | 3000 | 1.8V | Positive | 1 | 60dB(1kHz) | - |
| TI | TPS76325DBVR | SOT-23-5 | 3000 | 2.5V | Positive | 1 | 60dB(1kHz) | 600mV |
| TI | TPS76333DBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 60dB(1kHz) | 500mV |
| TI | TPS767D301PWPR | HTSSOP-28 | 2000 | Adjustable | Positive | 2 | 60dB(1kHz) | 575mV |
| TI | TPS76933DBVR(PB-FREE) | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 60dB(1kHz) | 200mV |
| TI | TPS78101DDCR | SOT-23-5 | 3000 | Adjustable | Positive | 1 | 40dB | - |
| TI | TPS78230DDCR | SOT-23-5 | 3000 | 3.0V | Positive | 1 | 40dB | 250mV |
| TI | TPS78233DDCR | TSOT-23-5 | 3000 | 3.3V | Positive | 1 | 40dB | 250mV |
| TI | TPS79301DBVR | SOT-23-6 | 3000 | Adjustable | Positive | 1 | 70dB | - |
| TI | TPS79333DBVR | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 70dB | 180mV |
| TI | TPS7A4101DGNR | MSOP-8 | 2500 | Adjustable | Positive | 1 | 65dB(100Hz) | 1.3V |
| TI | TPS7A4901DGNR | MSOP-8 | 2500 | Adjustable | Positive | 1 | 78dB(1kHz) | 450mV |
| TI | TPS7A8001DRBR | VSON-8 | 3000 | Adjustable | Positive | 1 | 48dB | 500mV |
| TI | TPS7A8300RGWR | VQFN-20 | 3000 | Adjustable | Positive | 1 | 40dB(1MHz) | 200mV |
| TI | TPS7B6933QDCYRQ1 | SOT-223 | 2500 | 3.3V | Positive | 1 | 60dB(100Hz) | 800mV |
| TI | TPS7B6950QDCYRQ1 | SOT-223 | 3000 | 5.0V | Positive | 1 | 60dB(100Hz) | 800mV |
| ON(安森美) | LM317BD2TG | TO-263-2 | 50 | Adjustable | Positive | 1 | 80dB | - |
| ON(安森美) | LM317BD2TR4G | TO-263-2 | 800 | Adjustable | Positive | 1 | 80dB | - |
| ON(安森美) | LM317BTG | TO-220-3 | 50 | Adjustable | Positive | 1 | 80dB | - |
| ON(安森美) | LM317LBDR2G | SOIC-8 | 2500 | Adjustable | Positive | 1 | 80dB(120Hz) | - |
| ON(安森美) | LM317LZG | TO-92 | 2000 | Adjustable | Positive | 1 | 80dB(120Hz) | - |
| ON(安森美) | LM317MABTG | TO-220-3 | 50 | Adjustable | Positive | 1 | 80dB | - |
| ON(安森美) | LM317MBDTRKG | TO-252-2 | 2500 | Adjustable | Positive | 1 | 80dB | - |
| ON(安森美) | LM317MBSTT3G | SOT-223 | 4000 | Adjustable | Positive | 1 | 80dB | - |
| ON(安森美) | LM317MDTRKG | DPAK | 2500 | Adjustable | Positive | 1 | 80dB | - |
| ON(安森美) | LM79L05ACZ | TO-92-3 | 1000 | 5.0V | Negative | 1 | 60dB(120Hz) | 1.7V |
| ON(安森美) | LP2950ACZ-3.3G | TO-92-3 | 2000 | 3.3V | Positive | 1 | - | 450mV |
| ON(安森美) | LP2951ACDR2G | SOIC-8 | 2500 | Adjustable | Positive | 1 | - | 450mV |
| ON(安森美) | LP2951CDR2G | SOIC-8 | 2500 | Adjustable | Positive | 1 | - | 450mV |
| ON(安森美) | LP2951CMX | SOIC-8L | 3000 | Adjustable | Positive | 1 | - | 600mV |
| ON(安森美) | MC7805BDTRKG | TO-252-2 | 2500 | 5V | Positive | 1 | 68dB(120Hz) | 2V |
| ON(安森美) | MC7805BTG | TO-220-3 | 50 | 5V | Positive | 1 | 68dB(120Hz) | 2V |
| ON(安森美) | MC7805CD2TR4G | TO-263-2 | 800 | 5V | Positive | 1 | #VALUE! | 2V |
| ON(安森美) | MC7805CDTRKG | TO-252-2 | 2500 | 5V | Positive | 1 | #VALUE! | 2V |
| ON(安森美) | MC7805CTG | TO-220-3 | 50 | 5V | Positive | 1 | #VALUE! | 2V |
| ON(安森美) | MC7812ACTG | TO-220-3 | 50 | 12V | Positive | 1 | 60dB(120Hz) | 2V |
| ON(安森美) | MC7812BTG | TO-220-3 | 50 | 12V | Positive | 1 | 60dB(1kHz) | 2V |
| ON(安森美) | MC7812CTG | TO-220-3 | 50 | 12V | Positive | 1 | 60dB(1kHz) | 2V |
| ON(安森美) | MC7815BDTRKG | TO-252-2 | 2500 | 15V | Positive | 1 | 58dB(120Hz) | 2V |
| ON(安森美) | MC78L05ABDR2G | SOIC-8 | 2500 | 5V | Positive | 1 | 49dB(120Hz) | - |
| ON(安森美) | MC78L05ABPG | TO-92-3 | 2000 | 5V | Positive | 1 | 49dB(120Hz) | - |
| ON(安森美) | MC78L05ACDR2G | SOIC-8 | 2500 | 5V | Positive | 1 | 49dB(120Hz) | - |
| ON(安森美) | MC78L05ACPG | TO-92-3 | 2000 | 5V | Positive | 1 | 49dB(120Hz) | - |
| ON(安森美) | MC78L12ABPRPG | TO-92-3 | 2000 | 12V | Positive | 1 | 42dB(120Hz) | - |
| ON(安森美) | MC78L15ACPG | TO-92-3 | 2000 | 15V | Positive | 1 | 39dB(120Hz) | - |
| ON(安森美) | MC78LC33NTRG | SOT-23-5 | 3000 | 3.3V | Positive | 1 | - | 53mV |
| ON(安森美) | MC78M05ABDTRKG | TO-252-2 | 2500 | 5V | Positive | 1 | 80dB(120Hz) | 2V |
| ON(安森美) | MC78M05BDTRKG | TO-252-2 | 2500 | 5V | Positive | 1 | 80dB(120Hz) | - |
| ON(安森美) | MC78M09CDTRKG | TO-252-2 | 2500 | 9V | Positive | 1 | 80dB(120Hz) | - |
| ON(安森美) | MC78M12CDTG | TO-252-2 | 75 | 12V | Positive | 1 | 80dB(120Hz) | 2V |
| ON(安森美) | MC78M12CDTRKG | TO-252-2 | 2500 | 12V | Positive | 1 | 80dB(120Hz) | - |
| ON(安森美) | MC78M15BDTRKG | TO-252-2 | 2500 | 15V | Positive | 1 | #VALUE! | - |
| ON(安森美) | MC78M15CDTRKG | TO-252-2 | 2500 | 15V | Positive | 1 | 70dB(120Hz) | - |
| ON(安森美) | MC7912BD2TR4G | D2PAK | 800 | 12V | Negative | 1 | 61dB(120Hz) | 1.3V |
| ON(安森美) | MC7915BTG | TO-220-3 | 50 | 15V | Negative | 1 | 60dB(120Hz) | 1.3V |
| ON(安森美) | MC7918CTG | TO-220-3 | 50 | 5V | Negative | 1 | 59dB(120Hz) | 1.3V |
| ON(安森美) | MC79L05ABDR2G | SOIC-8 | 2500 | 5V | Negative | 1 | 49dB(120Hz) | 1.7V |
| ON(安森美) | MC79L05ACDR2G | SOIC-8 | 2500 | 5V | Negative | 1 | 49dB(120Hz) | 1.7V |
| ON(安森美) | MC79L05ACPG | TO-92-3 | 2000 | 5V | Negative | 1 | 49dB(120Hz) | 1.7V |
| ON(安森美) | MC79L12ACPG | TO-92-3 | 400 | 12V | Negative | 1 | 42dB(120Hz) | 1.7V |
| ON(安森美) | MC79M05BDTRKG | TO-252-2 | 2500 | 5V | Negative | 1 | #VALUE! | 1.1V |
| ON(安森美) | MC79M05CDTRKG | TO-252-2 | 2500 | 5V | Negative | 1 | 66dB(120Hz) | 1.1V |
| ON(安森美) | MC79M12BDTRKG | TO-252-2 | 2500 | 12V | Negative | 1 | 60dB(120Hz) | 1.1V |
| ON(安森美) | MC79M12CDTRKG | TO-252-2 | 2500 | 12V | Negative | 1 | 60dB(120Hz) | 1.1V |
| ON(安森美) | MC79M15BTG | TO-220 | 50 | 15V | Negative | 1 | 60dB(120Hz) | 1.1V |
| ON(安森美) | MC79M15CDTRKG | TO-252-2 | 2500 | 1.5V | Negative | 1 | 60dB(120Hz) | 1.1V |
| ON(安森美) | NCP1117DT18RKG | TO-252-2 | 2500 | 1.2V | Positive | 1 | 70dB(120Hz) | 1.2V |
| ON(安森美) | NCP7805TG | TO-220-3 | 50 | 5V | Positive | 1 | 75dB(120Hz) | 2V |
| ON(安森美) | NCV1117DT18T5G | TO-252-2 | 2500 | 1.8V | Positive | 1 | 70dB(120Hz) | 1.2V |
| ON(安森美) | NCV1117STAT3G | SOT-223 | 4000 | Adjustable | Positive | 1 | 73dB(120Hz) | 1.2V |
| ON(安森美) | NCV317BD2TR4G | TO-263-2 | 800 | Adjustable | Positive | 1 | 80dB | - |
| ON(安森美) | NCV317LBDR2G | SOIC-8 | 2500 | Adjustable | Positive | 1 | 80dB(120Hz) | - |
| ON(安森美) | NCV4274ADT50RKG | TO-252-2 | 2500 | 5V | Positive | 1 | 60dB(100Hz) | 500mV |
| ON(安森美) | NCV7805BDTRKG | TO-252-2 | 2500 | 5V | Positive | 1 | 83dB(120Hz) | 2V |
| TI(德州仪器) | LM78L05ACMX/NOPB | SOIC-8 | 2500 | 5V | Positive | 1 | 62dB(120Hz) | - |
| TI(德州仪器) | LP5907QMFX-3.3Q1 | SOT-23-5 | 3000 | 3.3V | Positive | 1 | 90dB | 250mV |
| TI(德州仪器) | TLV1117IDCYR | SOT-223 | 2500 | Adjustable | Positive | 1 | 75dB(120Hz) | 1.3V |
| TI(德州仪器) | TPS74901RGWR | VQFN-20 | 3000 | Adjustable | Positive | 1 | 60dB | 280mV |
