Dual Digital Transistor-B&M TECH

Feel free to download our SPEC table for Dual Digital Transistor

HK B&M Digital Transistor SPEC Table
<-Return	www.bm-cs.com
Whatsapp/Wechat: +86-18621961382 Mail: sales@bm-cs.com or java.zhang@bm-cs.com
PN	Package	Polarity	IO(mA)	VCC(V)	Gi	VO(on) V	R1(kΩ)	R2(kΩ)	fT(MHz)	Equal Parts	Equal Circuit
UMA11N	SOT-353	PNP*2	100	50	80	0.3	4.7+	47+	250+	DTA143Z*2	DT-6
UMA3N	SOT-353	PNP*2	100	50	100	0.3	4.7+	INFINITY	250+	DTA143T*2	DT-8
UMA5N	SOT-353	PNP*2	100	50	80	0.3	2.2+	47+	250+	DTA123J*2	DT-6
UMA9N	SOT-353	PNP*2	50	50	20	0.3	10+	10+	250+	DTA114E*2	DT-6
UMB3N	SOT-363	PNP*2	100	50	100	0.3	4.7+	INFINITY	250+	DTA143T*2	DT-12
UMB4N	SOT-363	PNP*2	100	50	100	0.3	10+	INFINITY	250+	DTA114T*2	DT-12
UMC2N	SOT-353	NPN	100	50	56	0.3	22+	22+	250+	DTC124E	DT-9
UMC2N	SOT-353	PNP	100	50	56	0.3	22+	22+	250+	DTA124E	DT-9
UMC3N	SOT-353	NPN	100	50	30	0.3	10+	10+	250+	DTC114E	DT-9
UMC3N	SOT-353	PNP	100	50	30	0.3	10+	10+	250+	DTA114E	DT-9
UMC4N	SOT-353	NPN	100	50	68	0.3	47+	47+	250+	DTC144E	DT-9
UMC4N	SOT-353	PNP	100	50	68	0.3	10+	47+	250+	DTA114Y	DT-9
UMC5N	SOT-353	NPN	100	50	68	0.3	47+	47+	250+	DTC144E	DT-9
UMC5N	SOT-353	PNP	100	50	30	0.3	4.7+	10+	250+	DTA143X	DT-9
UMD2N	SOT-363	PNP	100	50	56	0.3	22+	22+	250+	DTA124E	DT-14
UMD2N	SOT-363	NPN	100	50	56	0.3	22+	22+	250+	DTC124E	DT-14
UMD3N	SOT-363	PNP	100	50	30	0.3	10+	10+	250+	DTA114E	DT-14
UMD3N	SOT-363	NPN	100	50	30	0.3	10+	10+	250+	DTC114E	DT-14
UMD5N	SOT-363	PNP	100	50	30	0.3	4.7+	10+	250+	DTA143X	DT-14
UMD5N	SOT-363	NPN	100	50	68	0.3	47+	47+	250+	DTC144E	DT-14
UMD6N	SOT-363	PNP	100	50	100	0.3	4.7+	INFINITY	250+	DTA143T	DT-10
UMD6N	SOT-363	NPN	100	50	100	0.3	4.7+	INFINITY	250+	DTC143T	DT-10
UMD9N	SOT-363	PNP	100	50	68	0.3	10+	47+	250+	DTA114Y	DT-14
UMD9N	SOT-363	NPN	100	50	68	0.3	10+	47+	250+	DTC114Y	DT-14
UMD10N	SOT-363	NPN	100	50	80	0.3	2.2+	47+	250+	DTC123J	DT-14
UMD10N	SOT-363	PNP	100	50	80	0.3	2.2+	47+	250+	DTA123J	DT-14
UMD12N	SOT-363	NPN	100	50	68	0.3	47+	47+	250+	DTC144E	DT-14
UMD12N	SOT-363	PNP	100	50	68	0.3	47+	47+	250+	DTA144E	DT-14
UMD15N	SOT-363	NPN	100	50	20	0.3	47+	47+	250+	DTC143E	DT-14
UMD15N	SOT-363	PNP	100	50	30	0.3	4.7+	4.7+	250+	DTA143E	DT-14
UMD22N	SOT-363	PNP	100	50	80	0.3	4.7+	47+	250+	DTA143Z	DT-14
UMD22N	SOT-363	NPN	100	50	80	0.3	4.7+	47+	250+	DTC143Z	DT-14
UMD48N	SOT-363	NPN	100	50	68	0.3	47+	47+	250+	DTC144E	DT-14
UMD48N	SOT-363	PNP	100	50	80	0.3	2.2+	47+	250+	DTA123J	DT-14
UMG2N	SOT-353	NPN*2	100	50	68	0.3	47+	47+	250+	DTC144E*2	DT-5
UMG3N	SOT-353	NPN*2	100	50	100	0.3	4.7+	INFINITY	250+	DTC143T*2	DT-7
UMG4N	SOT-353	NPN*2	100	50	100	0.3	10+	INFINITY	250+	DTC114T*2	DT-7
UMG5N	SOT-353	NPN*2	100	50	68	0.3	10+	47+	250+	DTC114Y*2	DT-5
UMH1N	SOT-363	NPN*2	100	50	56	0.3	22+	22+	250+	DTC124E*2	DT-15
UMH2N	SOT-363	NPN*2	100	50	68	0.3	47+	47+	250+	DTC144E*2	DT-15
UMH3N	SOT-363	NPN*2	100	50	100	0.3	4.7+	INFINITY	250+	DTC143T*2	DT-11
UMH4N	SOT-363	NPN*2	100	50	100	0.3	10+	INFINITY	250+	DTC114T*2	DT-11
UMH6N	SOT-363	NPN*2	100	50	68	0.3	47+	47+	250+	DTC144E*2	DT-17
UMH7N	SOT-363	NPN*2	100	50	100	0.3	4.7+	INFINITY	250+	DTC143T*2	DT-13
UMH9N	SOT-363	NPN*2	100	50	68	0.3	10+	47+	250+	DTC114Y*2	DT-15
UMH10N	SOT-363	NPN*2	100	50	80	0.3	2.2+	47+	250+	DTC123J*2	DT-15
UMH11N	SOT-363	NPN*2	100	50	30	0.3	10+	10+	250+	DTC114E*2	DT-15
UMH13N	SOT-363	NPN*2	100	50	80	0.3	4.7+	47+	250+	DTC143Z*2	DT-15
UMH14N	SOT-363	NPN*2	100	50	100	0.3	47+	INFINITY	250+	DTC144T*2	DT-13
UMH15N	SOT-363	NPN*2	100	50	100	0.3	47+	INFINITY	250+	DTC144T*2	DT-11
EMB3	SOT-563	PNP*2	100	50	100	0.3	4.7+	INFINITY	250+	DTA143T*2	DT-12
EMB4	SOT-563	PNP*2	100	50	100	0.3	10+	INFINITY	250+	DTA114T*2	DT-12
EMB9	SOT-563	PNP*2	100	50	68	0.3	10+	47+	250+	DTA114Y*2	DT-16
EMB11	SOT-563	PNP*2	100	50	30	0.3	10+	10+	250+	DTA114E*2	DT-16
EMD2	SOT-563	PNP	100	50	56	0.3	22+	22+	250+	DTA124E	DT-14
EMD2	SOT-563	NPN	100	50	56	0.3	22+	22+	250+	DTC124E	CIRCUIT54
EMD3	SOT-563	PNP	100	50	30	0.3	10+	10+	250+	DTA114E	DT-14
EMD3	SOT-563	NPN	100	50	30	0.3	10+	10+	250+	DTC114E	CIRCUIT54
EMD6	SOT-563	PNP	100	50	100	0.3	4.7+	INFINITY	250+	DTA143T	DT-10
EMD6	SOT-563	NPN	100	50	100	0.3	4.7+	INFINITY	250+	DTC143T	CIRCUIT54
EMD9	SOT-563	NPN	100	50	68	0.3	10+	47+	250+	DTC114Y	DT-14
EMD9	SOT-563	PNP	100	50	68	0.3	10+	47+	250+	DTA114Y	CIRCUIT54
EMD10	SOT-563	NPN	100	50	80	0.3	2.2+	47+	250+	DTC123J	DT-14
EMD10	SOT-563	PNP	100	50	80	0.3	2.2+	47+	250+	DTA123J	CIRCUIT54
EMD12	SOT-563	NPN	100	50	68	0.3	47+	47+	250+	DTC144E	DT-14
EMD12	SOT-563	PNP	100	50	68	0.3	47+	47+	250+	DTA144E	CIRCUIT54
EMD22	SOT-563	NPN	100	50	80	0.3	4.7+	47+	250+	DTC143Z	DT-14
EMD22	SOT-563	PNP	100	50	80	0.3	4.7+	47+	250+	DTA143Z	CIRCUIT54
EMD38	SOT-563	NPN	100	50	68	0.3	10+	47+	250+	DTC114Y	DT-14
EMD38	SOT-563	PNP	100	50	33	0.3	1+	10+	250+	DTA113Z	CIRCUIT54
EMG8	SOT-553	NPN*2	100	50	80	0.3	4.7+	47+	250+	DTC143Z*2	DT-5
EMG11	SOT-553	NPN*2	100	50	80	0.3	2.2+	47+	250+	DTC123J*2	DT-5
EMH1	SOT-563	NPN*2	100	50	56	0.3	22+	22+	250+	DTC124E*2	DT-15
EMH2	SOT-563	NPN*2	100	50	68	0.3	47+	47+	250+	DTC144E*2	DT-15
EMH3	SOT-563	NPN*2	100	50	100	0.3	4.7+	INFINITY	250+	DTC143T*2	DT-11
EMH4	SOT-563	NPN*2	100	50	100	0.3	10+	INFINITY	250+	DTC114T*2	DT-11
EMH9	SOT-563	NPN*2	100	50	68	0.3	10+	47+	250+	DTC114Y*2	DT-15
EMH10	SOT-563	NPN*2	100	50	80	0.3	2.2+	47+	250+	DTC123J*2	DT-15
EMH11	SOT-563	NPN*2	100	50	30	0.3	10+	10+	250+	DTC114E*2	DT-15
UMG8N	SOT-353	NPN*2	100	50	80	0.3	4.7+	47+	250+	DTC143Z*2	DT-5
