Darlington Transistor
Feel free todownloadour SPEC table for Darlington Transistor<HK B&M Darlington Transistor SPEC Table<-Returnwww.bm-cs.comWhatsapp/Wechat:+86-18621961382Mail:sales@bm-cs.com or java.zhang@bm-
Feel free to download our SPEC table for Darlington Transistor
<
| HK B&M Darlington Transistor SPEC Table | ||||||||||||||||
| <-Return | www.bm-cs.com | |||||||||||||||
| Whatsapp/Wechat: +86-18621961382 Mail: sales@bm-cs.com or java.zhang@bm-cs.com | ||||||||||||||||
| PN | Polarity | PinPos | PCM(mW) | IC(mA) | BVCBO(V) | BVCEO(V) | BVEBO(V) | hFE Min | hFE Max | VCE(V) | IC(mA) | VCE(sat) V | IC(mA) | IB(mA) | fT(MHz) | Package |
| 2SD2142 | NPN | BEC | 200 | 300 | 40 | 32 | 12 | 5000 | 3 | 100 | 1.4 | 200 | 0.2 | 200+ | SOT-23 | |
| BCV27 | NPN | BEC | 300 | 500 | 40 | 30 | 10 | 20000 | 5 | 100 | 1 | 100 | 0.1 | 170+ | SOT-23 | |
| BCV47 | NPN | BEC | 300 | 500 | 80 | 60 | 10 | 10000 | 5 | 100 | 1 | 100 | 0.1 | 170+ | SOT-23 | |
| BST52 | NPN | BCE | 500 | 500 | 90 | 80 | 2000 | 10 | 500 | 1.3 | 500 | 0.5 | 200+ | SOT-89-3L | ||
| CZT122 | NPN | BCE | 1000 | 5000 | 100 | 100 | 5 | 1000 | 3 | 3000 | 4 | 5000 | 20 | 4 | SOT-223 | |
| CZT127 | PNP | BCE | 1000 | 5000 | 100 | 100 | 5 | 1000 | 3 | 3000 | 4 | 5000 | 20 | 4 | SOT-223 | |
| MJD112 | NPN | BCE | 1500 | 2000 | 100 | 100 | 5 | 1000 | 12000 | 3 | 2000 | 3 | 4000 | 40 | 25 | TO-251-3L |
| MJD112 | NPN | BCE | 1500 | 2000 | 100 | 100 | 5 | 1000 | 12000 | 3 | 2000 | 3 | 4000 | 40 | 25 | TO-252-2L |
| MJD117 | PNP | BCE | 1750 | 2000 | 100 | 100 | 5 | 1000 | 12000 | 3 | 2000 | 3 | 4000 | 40 | 25 | TO-251-3L |
| MJD117 | PNP | BCE | 1750 | 2000 | 100 | 100 | 5 | 1000 | 12000 | 3 | 2000 | 3 | 4000 | 40 | 25 | TO-252-2L |
| MJD122 | NPN | BCE | 1500 | 8000 | 100 | 100 | 5 | 1000 | 12000 | 4 | 4000 | 2 | 4000 | 16 | TO-251-3L | |
| MJD122 | NPN | BCE | 1500 | 8000 | 100 | 100 | 5 | 1000 | 12000 | 4 | 4000 | 2 | 4000 | 16 | TO-252-2L | |
| MJD127 | PNP | BCE | 1500 | 8000 | 100 | 100 | 5 | 1000 | 12000 | 4 | 4000 | 4 | 8000 | 80 | TO-251-3L | |
| MJD127 | PNP | BCE | 1500 | 8000 | 100 | 100 | 5 | 1000 | 12000 | 4 | 4000 | 4 | 8000 | 80 | TO-252-2L | |
| MMBTA13 | NPN | BEC | 300 | 300 | 30 | 30 | 10 | 10000 | 5 | 100 | 1.5 | 100 | 0.1 | 125 | SOT-23 | |
| MMBTA14 | NPN | BEC | 300 | 300 | 30 | 30 | 10 | 20000 | 5 | 100 | 1.5 | 100 | 0.1 | 125 | SOT-23 | |
| MMBTA28 | NPN | BEC | 200 | 500 | 80 | 80 | 12 | 10000 | 5 | 10 | 1.2 | 10 | 0.01 | 125 | SOT-23 | |
| MMBTA64 | PNP | BEC | 300 | 800 | 30 | 30 | 10 | 20000 | 5 | 10 | 1.5 | 100 | 0.01 | 125 | SOT-23 | |
| MPSA13 | NPN | EBC | 625 | 500 | 30 | 30 | 10 | 10000 | 5 | 100 | 1.5 | 100 | 0.1 | 125 | TO-92 | |
| MPSA14 | NPN | EBC | 625 | 500 | 30 | 30 | 10 | 20000 | 5 | 100 | 1.5 | 100 | 0.1 | 125 | TO-92 | |
| MPSA27 | NPN | EBC | 625 | 500 | 60 | 60 | 10 | 10000 | 5 | 100 | 1.5 | 100 | 0.1 | 125 | TO-92 | |
| MPSA29 | NPN | EBC | 625 | 500 | 100 | 100 | 12 | 10000 | 5 | 100 | 1.5 | 100 | 0.1 | 125 | TO-92 | |
| PZTA14 | NPN | BCE | 1000 | 500 | 30 | 30 | 10 | 20000 | 5 | 100 | 1.5 | 100 | 0.1 | 125 | SOT-223 | |
| PZTA64 | PNP | BCE | 1000 | 500 | 30 | 30 | 10 | 20000 | 5 | 100 | 1.5 | 100 | 0.1 | 125 | SOT-223 | |
| TIP110 | NPN | BCE | 2000 | 2000 | 60 | 60 | 5 | 1000 | 4 | 1000 | 2.5 | 2000 | 8 | TO-220-3L | ||
| TIP111 | NPN | BCE | 2000 | 2000 | 80 | 80 | 5 | 1000 | 4 | 1000 | 2.5 | 2000 | 8 | TO-220-3L | ||
| TIP112 | NPN | BCE | 2000 | 2000 | 100 | 100 | 5 | 1000 | 4 | 1000 | 2.5 | 2000 | 8 | TO-220-3L | ||
| TIP117 | PNP | BCE | 2000 | 2000 | 100 | 100 | 5 | 1000 | 4 | 1000 | 2.5 | 2000 | 8 | TO-220-3L | ||
| TIP120 | NPN | BCE | 2000 | 5000 | 60 | 60 | 5 | 1000 | 3 | 500 | 4 | 5000 | 20 | TO-220-3L | ||
| TIP121 | NPN | BCE | 2000 | 5000 | 80 | 80 | 5 | 1000 | 3 | 500 | 4 | 5000 | 20 | TO-220-3L | ||
| TIP122 | NPN | BCE | 2000 | 5000 | 100 | 100 | 5 | 1000 | 3 | 500 | 4 | 5000 | 20 | TO-220-3L | ||
| TIP125 | PNP | BCE | 2000 | 5000 | 60 | 60 | 5 | 1000 | 3 | 500 | 4 | 5000 | 20 | TO-220-3L | ||
| TIP126 | PNP | BCE | 2000 | 5000 | 80 | 80 | 5 | 1000 | 3 | 500 | 4 | 5000 | 20 | TO-220-3L | ||
| TIP127 | PNP | BCE | 2000 | 5000 | 100 | 100 | 5 | 1000 | 3 | 500 | 4 | 5000 | 20 | TO-220-3L | ||
| TIP122F | NPN | BCE | 2000 | 5000 | 100 | 100 | 5 | 1000 | 3 | 500 | 4 | 5000 | 20 | TO-220F | ||
| TIP127F | PNP | BCE | 2000 | 5000 | 100 | 100 | 5 | 1000 | 3 | 500 | 4 | 5000 | 20 | TO-220F | ||
| TIP122 | NPN | ECB | 1250 | 5000 | 100 | 100 | 1000 | 3 | 500 | 2 | 3000 | 12 | TO-126 | |||
| TIP127 | PNP | ECB | 1250 | 5000 | 100 | 100 | 1000 | 3 | 500 | 2 | 3000 | 12 | TO-126 | |||
