Dual Transistor
Feel free todownloadour SPEC table for Dual Transistor<HK B&M Dual Transistor SPEC Table<-Returnwww.bm-cs.comWhatsapp/Wechat:+86-18621961382Mail:sales@bm-cs.com or java.zhang@bm-cs.comPNPola
Feel free to download our SPEC table for Dual Transistor
<
| HK B&M Dual Transistor SPEC Table | |||||||||||||||||
| <-Return | www.bm-cs.com | ||||||||||||||||
| Whatsapp/Wechat: +86-18621961382 Mail: sales@bm-cs.com or java.zhang@bm-cs.com | |||||||||||||||||
| PN | Polarity | PCM(mW) | IC(mA) | BVCBO(V) | BVCEO(V) | BVEBO(V) | hFE MIN | hFE MAX | VCE(V) | IC(mA) | VCE(sat V) | IC(mA) | IB(mA) | fT(MHz) | Equal Circuit | Package | Euqal Parts |
| 2SA1873 | PNP*2 | 200 | 150 | 50 | 50 | 5 | 120 | 400 | 6 | 2 | 0.3 | 100 | 10 | 80 | TR-5 | SOT-353 | 2SA1873*2 |
| 2SC4944 | NPN*2 | 200 | 150 | 60 | 50 | 5 | 120 | 400 | 6 | 2 | 0.25 | 100 | 10 | 80 | TR-4 | SOT-353 | 2SC4944*2 |
| BC846S | NPN*2 | 200 | 100 | 80 | 65 | 6 | 110 | 5 | 2 | 0.3 | 100 | 5 | 100 | TR-11 | SOT-363 | BC846*2 | |
| BC847BV | NPN*2 | 150 | 100 | 50 | 45 | 6 | 200 | 450 | 5 | 2 | 0.3 | 100 | 5 | 100 | TR-9 | SOT-563 | BC847*2 |
| BC847PN | NPN | 200 | 100 | 50 | 45 | 6 | 200 | 450 | 5 | 2 | 0.6 | 100 | 5 | 100 | TR-8 | SOT-363 | BC847W |
| PNP | 200 | 100 | 50 | 45 | 5 | 220 | 475 | 5 | 2 | 0.65 | 100 | 5 | 100 | BC857W | |||
| BC847S | NPN*2 | 200 | 100 | 50 | 45 | 6 | 110 | 630 | 5 | 2 | 0.25 | 10 | 0.5 | 200+ | TR-9 | SOT-363 | BC847*2 |
| BC856S | PNP*2 | 200 | 100 | 80 | 65 | 5 | 110 | 5 | 2 | 0.3 | 100 | 5 | 100 | TR-13 | SOT-363 | BC856*2 | |
| BC857BV | PNP*2 | 150 | 100 | 50 | 45 | 6 | 220 | 475 | 5 | 2 | 0.4 | 100 | 5 | 100 | TR-13 | SOT-563 | BC857*2 |
| BC857S | PNP*2 | 200 | 100 | 50 | 45 | 5 | 125 | 630 | 5 | 2 | 0.3 | 10 | 0.5 | 200+ | TR-13 | SOT-363 | BC857*2 |
| CJ2045 | NPN | 350 | 1500 | 40 | 30 | 7 | 180 | 500 | 2 | 100 | 0.375 | 750 | 15 | TR-17 | SOT-23-6L | SS8050 | |
| PNP | 350 | 1500 | 40 | 30 | 7 | 180 | 500 | 2 | 100 | 0.375 | 750 | 15 | SS8550 | ||||
| EMT1 | PNP*2 | 150 | 150 | 60 | 50 | 6 | 120 | 560 | 6 | 1 | 0.5 | 50 | 5 | 140+ | TR-13 | SOT-563 | 2SA1037AK*2 |
| EMT18 | PNP*2 | 150 | 500 | 15 | 12 | 6 | 270 | 680 | 2 | 10 | 0.25 | 200 | 10 | 260+ | TR-13 | SOT-563 | 2SA2018*2 |
| EMX1 | NPN*2 | 150 | 150 | 60 | 50 | 7 | 120 | 560 | 6 | 1 | 0.4 | 50 | 5 | 180+ | TR-9 | SOT-563 | 2SC2412K*2 |
| EMX18 | NPN*2 | 150 | 500 | 15 | 12 | 6 | 270 | 680 | 2 | 10 | 0.25 | 200 | 10 | 320+ | TR-9 | SOT-563 | 2SC5585*2 |
| EMY1 | PNP | 150 | 150 | 60 | 50 | 6 | 120 | 560 | 6 | 1 | 0.5 | 50 | 5 | 140+ | TR-6 | SOT-553 | 2SA1037AK |
| NPN | 150 | 150 | 60 | 50 | 7 | 120 | 560 | 6 | 1 | 0.4 | 50 | 5 | 180+ | 2SC2412K | |||
| EMZ8 | PNP | 150 | 150 | 15 | 12 | 6 | 270 | 680 | 2 | 10 | 0.25 | 200 | 10 | 260+ | TR-14 | SOT-563 | 2SA2018 |
| NPN | 150 | 150 | 60 | 50 | 7 | 120 | 560 | 6 | 1 | 0.4 | 50 | 5 | 180+ | 2SC2412K | |||
| MMDT2222A | NPN*2 | 200 | 600 | 75 | 40 | 6 | 100 | 300 | 10 | 150 | 1 | 500 | 50 | 300 | TR-9 | SOT-363 | MMBT2222A*2 |
| MMDT2227 | NPN | 200 | 600 | 75 | 40 | 6 | 100 | 300 | 10 | 150 | 1 | 500 | 50 | 300 | TR-8 | SOT-363 | MMBT2222A |
| PNP | 200 | 600 | 60 | 60 | 5 | 100 | 300 | 10 | 150 | 1.6 | 500 | 50 | 200 | MMBT2907A | |||
| MMDT2907A | PNP*2 | 200 | 600 | 60 | 60 | 5 | 100 | 300 | 10 | 150 | 1.6 | 500 | 50 | 200 | TR-13 | SOT-363 | MMBT2907A*2 |
| MMDT3904 | NPN*2 | 200 | 200 | 60 | 40 | 5 | 100 | 300 | 1 | 10 | 0.3 | 50 | 5 | 300 | TR-9 | SOT-363 | MMBT3904*2 |
| MMDT3906 | PNP*2 | 200 | 200 | 40 | 40 | 5 | 100 | 300 | 1 | 10 | 0.4 | 50 | 5 | 250 | TR-13 | SOT-363 | MMBT3906*2 |
| MMDT3946 | PNP | 200 | 200 | 60 | 40 | 5 | 100 | 300 | 1 | 10 | 0.4 | 50 | 5 | 250 | TR-14 | SOT-363 | MMBT3906 |
| NPN | 200 | 200 | 40 | 40 | 5 | 100 | 300 | 1 | 10 | 0.3 | 50 | 5 | 300 | MMBT3904 | |||
| MMDT4401 | NPN*2 | 200 | 600 | 60 | 40 | 6 | 100 | 300 | 1 | 150 | 0.75 | 500 | 50 | 250 | TR-9 | SOT-363 | MMBT4401*2 |
| MMDT4403 | PNP*2 | 200 | 600 | 40 | 40 | 5 | 100 | 300 | 2 | 150 | 0.75 | 500 | 50 | 200 | TR-13 | SOT-363 | MMBT4403*2 |
| MMDT4413 | NPN | 200 | 600 | 60 | 40 | 6 | 100 | 300 | 1 | 150 | 0.75 | 500 | 50 | 250 | TR-8 | SOT-363 | MMBT4401 |
| PNP | 200 | 600 | 40 | 40 | 5 | 100 | 300 | 2 | 150 | 0.75 | 500 | 50 | 200 | MMBT4403 | |||
| MMDT5401 | PNP*2 | 200 | 200 | 160 | 150 | 5 | 100 | 300 | 5 | 10 | 0.5 | 50 | 5 | 100 | TR-13 | SOT-363 | MMBT5401*2 |
| MMDT5451 | NPN | 200 | 200 | 180 | 160 | 6 | 100 | 300 | 5 | 10 | 0.2 | 50 | 5 | 100 | TR-8 | SOT-363 | MMBT5401 |
| PNP | 200 | 200 | 160 | 150 | 5 | 100 | 300 | 5 | 10 | 0.5 | 50 | 5 | 100 | MMBT5551 | |||
| MMDT5551 | NPN*2 | 200 | 200 | 180 | 160 | 6 | 100 | 300 | 5 | 10 | 0.15 | 10 | 1 | 100 | TR-9 | SOT-363 | MMBT5551*2 |
| MMDT9014 | NPN*2 | 200 | 100 | 50 | 45 | 5 | 300 | 400 | 5 | 1 | 0.3 | 100 | 5 | 150 | TR-9 | SOT-363 | S9014*2 |
| NST3946 | NPN | 150 | 200 | 60 | 40 | 5 | 100 | 300 | 1 | 10 | 0.3 | 50 | 5 | 300 | TR-8 | SOT-563 | MMBT3904 |
| PNP | 150 | 200 | 40 | 40 | 5 | 100 | 300 | 1 | 10 | 0.4 | 50 | 5 | 250 | MMBT3906 | |||
| UMT1N | PNP*2 | 150 | 150 | 60 | 50 | 6 | 120 | 560 | 6 | 1 | 0.5 | 50 | 5 | 140+ | TR-13 | SOT-363 | 2SA1037AK*2 |
| UMT2N | PNP*2 | 150 | 150 | 60 | 50 | 6 | 120 | 560 | 6 | 1 | 0.5 | 50 | 5 | 140+ | TR-16 | SOT-363 | 2SA1037AK*2 |
| UMX1N | NPN*2 | 150 | 150 | 60 | 50 | 7 | 120 | 560 | 6 | 1 | 0.4 | 50 | 5 | 180+ | TR-9 | SOT-363 | 2SC2412K*2 |
| UMX2N | NPN*2 | 150 | 150 | 60 | 50 | 7 | 120 | 560 | 6 | 1 | 0.4 | 50 | 5 | 180+ | TR-12 | SOT-363 | 2SC2412K*2 |
| UMX3N | NPN*2 | 150 | 150 | 60 | 50 | 7 | 120 | 560 | 6 | 1 | 0.4 | 50 | 5 | 180+ | TR-11 | SOT-363 | 2SC2412K*2 |
| UMX18N | NPN*2 | 150 | 500 | 15 | 12 | 6 | 270 | 680 | 2 | 10 | 0.25 | 200 | 10 | 320+ | TR-9 | SOT-363 | 2SC5585*2 |
| UMY1N | PNP | 150 | 150 | 60 | 50 | 6 | 120 | 560 | 6 | 1 | 0.5 | 50 | 5 | 140+ | TR-6 | SOT-353 | 2SA1037AK |
| NPN | 150 | 150 | 60 | 50 | 7 | 120 | 560 | 6 | 1 | 0.4 | 50 | 5 | 180+ | 2SC2412K | |||
| UMZ1N | NPN | 150 | 150 | 60 | 50 | 7 | 120 | 560 | 6 | 1 | 0.4 | 50 | 5 | 180+ | TR-8 | SOT-363 | 2SC2412K |
| PNP | 150 | 150 | 60 | 50 | 7 | 120 | 560 | 6 | 1 | 0.5 | 50 | 5 | 140+ | 2SA1037AK | |||
| UMZ2N | PNP | 150 | 150 | 60 | 50 | 6 | 120 | 560 | 6 | 1 | 0.5 | 50 | 5 | 140+ | TR-15 | SOT-363 | 2SA1037AK |
| NPN | 150 | 150 | 60 | 50 | 7 | 120 | 560 | 6 | 1 | 0.4 | 50 | 5 | 180+ | 2SC2412K | |||
| DMMT5551S | NPN*2 | 300 | 600 | 180 | 160 | 6 | 100 | 300 | 5 | 10 | 0.2 | 50 | 5 | 100 | TR-19 | SOT-23-6L | MMBT5551*2 |
| 2SC1583 | NPN*2 | 350 | 100 | 50 | 50 | 5 | 250 | 600 | 2 | 1 | 0.6 | 10 | 1 | 150+ | TR-4 | SOT-23-6L | 2SC2412K*2 |
| MMDT3904V | NPN*2 | 200 | 200 | 60 | 40 | 5 | 100 | 300 | 1 | 10 | 0.3 | 50 | 5 | 300 | TR-9 | SOT-563 | MMBT3904*2 |
