Feel free to download our SPEC table for Transistor

HK B&M Transistor SPEC Table
<-Return	www.bm-cs.com
Whatsapp/Wechat: +86-18621961382 Mail: sales@bm-cs.com or java.zhang@bm-cs.com
PN	Package	Polarity	PCM(mW)	IC(mA)	BVCBO(V)	BVCEO(V)	BVEBO(V)	hFE Min	hFE Max	VCE(V)	IC(mA)	VCE(sat V)	IC(mA)	IB(mA)	fT(MHz)
2SA1036	SOT-23	PNP	200	500	40	32	5	82	390	3	10	0.4	100	10	200
2SA1037	SOT-23	PNP	200	150	60	50	6	120	560	6	1	0.5	50	5	140
2SA1162	SOT-23	PNP	150	150	50	50	5	70	400	6	2	0.3	100	10	80
2SA1179	SOT-23	PNP	200	150	55	50	5	200	400	6	1	0.5	50	5	180
2SA1235A	SOT-23	PNP	200	200	60	50	6	150	500	6	1	0.3	100	10	200
2SA1298	SOT-23	PNP	200	800	35	30	5	100	320	1	100	0.4	500	20	120
2SA1313	SOT-23	PNP	200	500	50	50	5	70	240	1	100	0.25	100	10	200
2SA812	SOT-23	PNP	200	100	60	50	5	90	600	6	1	0.3	100	10	180
2SB1116	SOT-23	PNP	350	1000	60	50	6	135	600	2	100	0.3	1000	50	70
2SB1197	SOT-23	PNP	200	800	40	32	5	82	390	3	100	0.5	500	50	50
2SB1198	SOT-23	PNP	200	500	80	80	5	120	390	3	100	0.5	500	50	180
2SB624	SOT-23	PNP	200	700	30	25	5	110	400	1	100	0.6	700	70	160
2SB709A	SOT-23	PNP	200	100	45	45	7	160	460	10	2	0.5	100	10	60
2SC1623	SOT-23	NPN	200	100	60	50	5	90	600	6	1	0.3	100	10	250
2SC1654	SOT-23	NPN	150	50	180	160	5	90	400	3	15	0.3	50	5	120
2SC2411	SOT-23	NPN	200	500	40	32	5	82	390	3	100	0.4	500	50	250
2SC2412	SOT-23	NPN	200	150	60	50	7	120	560	6	1	0.4	50	5	160
2SC2712	SOT-23	NPN	150	150	60	50	5	70	700	6	2	0.25	100	10	80
2SC2714	SOT-23	NPN	100	20	40	30	4	40	200	6	1				550
2SC2715	SOT-23	NPN	350	50	35	30	4	40	240	12	2	0.4	10	1	100
2SC2717	SOT-23	NPN	300	50	30	25	4	90	320	12.5	12.5	0.2	15	1.5	300
2SC2859	SOT-23	NPN	150	500	35	30	5	70	400	1	100	0.25	100	10	300
2SC3052	SOT-23	NPN	150	200	50	50	6	150	800	6	1	0.3	100	10	180
2SC3437	SOT-23	NPN	150	200	40	15	5	40	240	1	10	0.3	20	1	200
2SC5343	SOT-23	NPN	200	150	60	50	5	70	700	6	2	0.25	100	10	80
2SC5344	SOT-23	NPN	200	800	35	30	5	100	320	1	100	0.5	500	50	120
2SC5345	SOT-23	NPN	300	20	30	20	4	40	240	6	1	0.3	10	1	550
2SD0602	SOT-23	NPN	200	500	30	25	5	85	340	10	150	0.6	300	30	200
2SD0602A	SOT-23	NPN	200	500	60	50	5	85	340	10	150	0.6	300	30	200
2SD1306	SOT-23	NPN	150	700	30	15	5	250	800	1	150	0.5	500	50	250
2SD1757K	SOT-23	NPN	200	500	30	15	6.5	120	560	3	100	0.4	500	50	150
2SD1781	SOT-23	NPN	200	800	40	32	5	120	390	3	100	0.4	500	50	150
2SD1782	SOT-23	NPN	200	500	80	80	5	120	390	3	100	0.5	500	50	120
2SD2114	SOT-23	NPN	250	500	25	20	12	820	2700	3	10	0.4	500	20	350
2SD596	SOT-23	NPN	200	700	30	25	5	110	400	1	100	0.6	700	70	170
2SD601A	SOT-23	NPN	200	100	60	50	7	160	460	10	2	0.3	100	10	150
2SD602	SOT-23	NPN	200	500	30	25	5	85	340	10	150	0.6	300	30	200
2SD602A	SOT-23	NPN	200	500	60	50	5	85	340	10	150	0.6	300	30	200
3DK2222A	SOT-23	NPN	225	600	75	40	6	100	300	10	150	0.6	500	50	300
A1015	SOT-23	PNP	200	150	50	50	5	130	400	6	2	0.3	100	10	80
A733	SOT-23	PNP	200	150	60	50	5	120	475	6	1	0.3	100	10	50
BC807	SOT-23	PNP	300	500	50	45	5	100	600	1	100	0.7	500	50	100
BC808	SOT-23	PNP	300	800	30	25	5	100	630	1	100	0.7	500	50	100
BC817	SOT-23	NPN	300	500	50	45	5	100	600	1	100	0.7	500	50	100
BC818	SOT-23	NPN	300	500	30	25	5	100	630	1	100	0.7	500	50	170
BC846	SOT-23	NPN	200	100	80	65	6	110	450	5	2	0.5	100	5	100
BC847	SOT-23	NPN	200	100	50	45	6	110	800	5	2	0.5	100	5	100
BC848	SOT-23	NPN	200	100	30	30	6	110	800	5	2	0.5	100	5	100
BC856	SOT-23	PNP	200	100	80	65	5	125	475	5	2	0.5	100	5	100
BC857	SOT-23	PNP	200	100	50	45	5	125	800	5	2	0.5	100	5	100
BC858	SOT-23	PNP	200	100	30	30	5	125	800	5	2	0.5	100	5	100
BCW61	SOT-23	PNP	250	100	32	32	5	120	630	5	2	0.55	50	1.25	100
BCW66	SOT-23	NPN	200	800	75	45	5	100	630	1	100	0.7	500	50	100
BCW68	SOT-23	PNP	330	800	60	45	5	100	630	1	100	0.7	500	50	200
BCX19	SOT-23	NPN	225	500	50	45	5	100	600	1	100	0.62	500	50
BCX70J	SOT-23	NPN	250	200	45	45	5	250	460	5	2	0.55	50	1.25	100
BCX70K	SOT-23	NPN	250	200	45	45	5	380	630	5	2	0.55	50	1.25	100
BF820	SOT-23	NPN	250	50	300	300	5	50		20	25	0.6	30	5	60
BF821	SOT-23	PNP	250	50	300	300	5	50		20	25	0.8	30	5	60
BF822	SOT-23	NPN	250	50	250	250	5	50		20	25	0.6	30	5	60
BF823	SOT-23	PNP	250	50	250	250	5	50		20	25	0.8	30	5	60
BFS20	SOT-23	NPN	250	25	30	20	4	40	120	10	7	0.3	10	1	275
C1815	SOT-23	NPN	200	150	60	50	5	130	400	6	2	0.25	100	10	80
C945	SOT-23	NPN	200	150	60	50	5	130	400	6	1	0.3	100	10	150
CJ201NL	SOT-23	NPN	300	1000	30	20	5	300		2	500	0.25	1000	50	100
FMMT4124	SOT-23	NPN	330	200	30	25	5	120	360	1	2	0.3	50	5	300
FMMT449	SOT-23	NPN	200	1000	50	30	5	100	300	2	500	1	2000	200	150
FMMT491	SOT-23	NPN	250	1000	80	60	5	100	300	5	500	0.5	1000	100	150
FMMT493	SOT-23	NPN	250	1000	120	100	5	100	300	10	250	0.6	1000	100	150
FMMT591	SOT-23	PNP	250	1000	80	60	5	100	300	5	500	0.6	1000	100	150
FMMT593	SOT-23	PNP	250	1000	120	100	5	100	300	5	500	0.3	500	50	50
FMMT619	SOT-23	NPN	350	2000	50	50	5	200		2	1000	0.22	2000	100	100
FMMT720	SOT-23	PNP	350	1500	40	40	5	180		2	1000	0.33	1500	100	150
KSA1182	SOT-23	PNP	150	500	35	30	5	70	240	1	100	0.25	100	10	200
KTA1298	SOT-23	PNP	200	800	35	30	5	100	320	1	100	0.4	500	20	120
KTA1504	SOT-23	PNP	150	150	50	50	5	70	400	6	2	0.3	100	10	80
KTA1505	SOT-23	PNP	150	500	35	30	5	70	400	1	100	0.25	100	10	200
KTC3265	SOT-23	NPN	200	800	35	30	5	100	320	1	100	0.5	500	20	120
KTC3875	SOT-23	NPN	150	150	60	50	5	70	700	6	2	0.25	100	10	80
KTC3876	SOT-23	NPN	200	500	35	30	5	70	400	1	100	0.25	100	10	300
KTC3879	SOT-23	NPN	150	50	35	30	4	40	240	12	2	0.4	10	1	100
KTC4075	SOT-23	NPN	100	150	60	50	5	70	700	6	2	0.25	100	10	80
KTD1304	SOT-23	NPN	200	300	25	20	12	200	1000	2	4	0.25	100	10	60
M28S	SOT-23	NPN	200	1000	40	20	6	300	1000	1	100	0.55	600	20	100
M8050	SOT-23	NPN	200	800	40	25	6	80	400	1	100	0.5	800	80	150
M8550	SOT-23	PNP	200	800	40	25	6	85	400	1	100	0.5	800	80	150
MMBT1616A	SOT-23	NPN	350	1000	120	60	6	135	600	2	100	0.3	1000	50	100
MMBT2222	SOT-23	NPN	250	600	75	30	6	100	300	10	150	1	500	50	300
MMBT2222A	SOT-23	NPN	300	600	75	40	6	100	300	10	150	1	500	50	300
MMBT2907	SOT-23	PNP	250	600	60	40	5	100	300	10	150	0.67	500	50	200
MMBT2907A	SOT-23	PNP	250	600	60	60	5	100	300	10	150	1.6	500	50	200
MMBT3904	SOT-23	NPN	200	200	60	40	6	100	300	1	10	0.3	50	5	300
MMBT3906	SOT-23	PNP	200	200	40	40	5	100	300	1	10	0.3	50	5	300
MMBT4401	SOT-23	NPN	300	600	60	40	6	100	300	1	150	0.4	150	15	250
MMBT4403	SOT-23	PNP	300	600	40	40	5	100	300	2	150	0.4	150	15	200
MMBT5401	SOT-23	PNP	300	600	160	150	5	100	300	5	10	0.5	50	5	100
MMBT5550	SOT-23	NPN	225	600	160	140	6	60	250	5	10	0.25	50	5
MMBT5551	SOT-23	NPN	300	600	180	160	6	100	300	5	10	0.2	50	5	80
MMBT589	SOT-23	PNP	310	1000	50	30	5	100	300	2	500	0.65	2000	200	100
MMBTA05	SOT-23	NPN	300	500	60	60	4	100	400	1	10	0.25	100	10	100
MMBTA06	SOT-23	NPN	300	500	80	80	4	100	400	1	10	0.25	100	10	100
MMBTA42	SOT-23	NPN	350	500	300	300	5	100	200	10	10	0.2	20	2	50
MMBTA43	SOT-23	NPN	350	500	200	200	5	40		10	10	0.5	20	2	50
MMBTA44	SOT-23	NPN	350	300	400	400	6	50	200	10	10	0.75	50	5
MMBTA55	SOT-23	PNP	225	500	60	60	4	100	400	1	10	0.25	100	10	50
MMBTA56	SOT-23	PNP	225	500	80	80	4	100	400	1	10	0.25	100	10	50
MMBTA92	SOT-23	PNP	300	500	300	300	5	100	200	10	10	0.2	20	2	50
MMBTA93	SOT-23	PNP	350	500	200	200	5	40		10	10	0.5	20	2	50
MMBTA94	SOT-23	PNP	350	300	400	400	5	80	300	10	10	0.3	50	5	50
MMBTH10	SOT-23	NPN	225	50	30	25	3	60		10	4	0.5	4	0.4	650
S8050	SOT-23	NPN	300	500	40	25	5	120	400	1	50	0.6	500	50	150
S8550	SOT-23	PNP	300	500	40	25	5	120	400	1	50	0.6	500	50	150
S9012	SOT-23	PNP	300	500	40	25	5	120	400	1	50	0.6	500	50	150
S9013	SOT-23	NPN	300	500	40	25	5	120	400	1	50	0.6	500	50	150
S9014	SOT-23	NPN	200	100	50	45	5	200	1000	5	1	0.3	100	5	150
S9015	SOT-23	PNP	200	100	50	45	5	200	1000	5	1	0.3	100	10	150
S9018	SOT-23	NPN	200	50	30	15	5	70	190	5	1	0.5	10	1	800
SS8050	SOT-23	NPN	300	1500	40	25	5	120	400	1	100	0.5	800	80	100
SS8550	SOT-23	PNP	300	1500	40	25	5	120	400	1	100	0.5	800	80	100
STD123S	SOT-23	NPN	350	1000	20	15	6.5	150		1	100	0.3	500	50	260
2SA1585	SOT-23	PNP	350	2000	20	20	6	120	560	2	200	0.5	2000	100	240
FMMT495	SOT-23	NPN	250	1000	170	150	5	100	300	10	250	0.3	500	50	100
8550SS	SOT-23	PNP	300	1500	40	25	5	200	350	1	100	0.5	800	80	100
FMMT618	SOT-23	PNP	350	2500	20	20	5	200		2	2000	0.2	2500	50	100
FMMT718	SOT-23	PNP	350	1500	20	20	7	300		2	100	0.22	1500	50	150
2SA1037K	SOT-23-3L	PNP	400	150	60	50	6	120	560	6	1	0.5	50	5	140
2SA1235A	SOT-23-3L	PNP	400	200	60	50	6	150	500	6	1	0.3	100	10	200
2SC2412K	SOT-23-3L	NPN	400	150	60	50	7	120	560	6	1	0.4	50	5	150
2SC3138	SOT-23-3L	NPN	400	50	200	200	5	120	240	3	10	0.5	10	1	50
2SC3928A	SOT-23-3L	NPN	400	200	50	50	6	120	820	6	1	0.3	100	10	200
MMBT2222A	SOT-23-3L	NPN	400	600	75	40	6	100	300	10	150	0.6	500	50	300
MMBT2907A	SOT-23-3L	PNP	400	600	60	60	5	100	300	10	150	1.6	500	50	200
2PD601AW	SOT-323	NPN	200	100	60	50	6	160	460	10	2	0.5	100	10	100
2SA1576A	SOT-323	PNP	200	150	60	50	6	120	560	6	1	0.5	50	5	140
2SA1577	SOT-323	PNP	200	500	40	32	5	82	390	3	10	0.4	100	10	200
2SA1579	SOT-323	PNP	100	50	120	120	5	180	560	6	2	0.5	10	1	140
2SA1586	SOT-323	PNP	100	150	50	50	5	70	400	6	2	0.3	100	10	80
2SA1611	SOT-323	PNP	150	100	60	50	5	90	600	6	1	0.3	100	10	180
2SB1218A	SOT-323	PNP	150	100	45	45	7	160	460	10	2	0.5	100	10	80
2SB1694	SOT-323	PNP	200	1000	30	30	6	270	680	2	100	0.38	500	25	320
2SC1623	SOT-323	NPN	200	100	60	50	5	90	600	6	1	0.3	100	10	250
2SC3930	SOT-323	NPN	150	30	30	20	5	70	220	10	1				150
2SC4081	SOT-323	NPN	200	150	60	50	7	120	560	6	1	0.4	50	5	180
2SC4097	SOT-323	NPN	200	500	40	32	5	82	390	3	10	0.4	500	50	250
2SC4098	SOT-323	NPN	200	50	40	25	5	56	270	6	1	0.3	10	1	150
2SC4102	SOT-323	NPN	200	50	120	120	5	180	560	6	2	0.5	10	1	140
2SC4116	SOT-323	NPN	100	150	60	50	5	70	700	6	2	0.25	100	10	80
2SC4177	SOT-323	NPN	150	100	60	50	5	90	600	6	1	0.3	100	10	250
2SC4180	SOT-323	NPN	150	50	120	120	5	135	900	6	1	0.3	10	1	50
2SC4215	SOT-323	NPN	100	20	40	30	4	40	200	6	1				260
2SD1819A	SOT-323	NPN	150	100	60	50	7	160	460	10	2	0.3	100	10	150
BC807W	SOT-323	PNP	200	500	50	45	5	100	600	1	100	0.7	500	50	80
BC817W	SOT-323	NPN	200	500	50	45	5	100	600	1	100	0.7	500	50	100
BC846W	SOT-323	NPN	150	100	80	65	6	110	450	5	2	0.6	100	5	100
BC847W	SOT-323	NPN	150	100	50	45	6	110	800	5	2	0.6	100	5	100
BC848W	SOT-323	NPN	150	100	30	30	5	110	800	5	2	0.6	100	5	100
BC856W	SOT-323	PNP	150	100	80	65	5	125	475	5	2	0.65	100	5	100
BC857W	SOT-323	PNP	150	100	50	45	5	125	800	5	2	0.65	100	5	100
BC858W	SOT-323	PNP	150	100	30	30	5	125	800	5	2	0.65	100	5	100
KTA2014	SOT-323	PNP	100	150	50	50	5	70	400	6	2	0.3	100	10	80
KTA2015	SOT-323	PNP	100	500	35	30	5	70	240	1	100	0.25	100	10	200
KTC4075	SOT-323	NPN	100	150	60	50	5	70	700	6	2	0.25	100	10	80
KTC4076	SOT-323	NPN	100	500	35	30	5	70	240	1	100	0.25	100	10	300
KTC4077	SOT-323	NPN	100	100	120	120	5	200	700	6	2	0.3	10	1	100
MMST2222A	SOT-323	NPN	200	600	75	40	6	100	300	10	150	1	500	50	300
MMST2907A	SOT-323	PNP	200	600	60	60	5	100	300	10	150	1.6	500	50	200
MMST3904	SOT-323	NPN	200	200	60	40	5	100	300	1	10	0.3	50	5	300
MMST3906	SOT-323	PNP	200	200	40	40	5	100	300	1	10	0.3	50	5	250
MMST4401	SOT-323	NPN	200	600	60	40	6	100	300	1	150	0.75	500	50	250
MMST4403	SOT-323	PNP	200	600	40	40	5	100	300	2	150	0.75	500	50	200
MMST5401	SOT-323	PNP	200	600	160	150	5	60	300	5	10	0.5	50	5	100
MMST5551	SOT-323	NPN	200	600	180	160	6	80	300	5	10	0.2	50	5	100
MMSTA42	SOT-323	NPN	200	500	300	300	5	100	200	10	10	0.2	20	2	50
MMSTA56	SOT-323	PNP	200	500	80	80	4	50		1	100	0.25	100	10	50
MMSTA92	SOT-323	PNP	200	500	310	305	5	100	200	10	10	0.2	20	2	50
S9012W	SOT-323	PNP	200	500	40	25	5	120	400	1	50	0.6	500	50	150
S9013W	SOT-323	NPN	200	500	40	25	5	120	400	1	50	0.6	500	50	150
S9014W	SOT-323	NPN	200	100	50	45	5	200	1000	5	1	0.3	100	5	150
S9015W	SOT-323	PNP	200	100	50	45	5	200	1000	5	1	0.3	100	10	150
S9018W	SOT-323	NPN	200	50	30	15	5	70	190	5	1	0.5	10	1	600
SS8050	SOT-323	NPN	250	1500	40	25	5	120	400	1	100	0.5	800	80	100
SS8550	SOT-323	PNP	200	1500	40	25	5	120	400	1	100	0.5	800	80	100
ZUMT491	SOT-323	NPN	250	1000	80	60	5	100	300	5	500	0.5	1000	100	150
2SA1774	SOT-523	PNP	150	150	60	50	6	120	560	6	1	0.5	50	5	140
2SA1832	SOT-523	PNP	100	150	50	50	5	120	400	6	2	0.3	100	10	80
2SA2018	SOT-523	PNP	150	500	15	12	6	270	680	2	10	0.25	200	10	260
2SC4617	SOT-523	NPN	150	150	60	50	7	120	560	6	1	0.4	50	5	180
2SC4618	SOT-523	NPN	150	50	40	25	5	56	270	6	1	0.3	10	1	150
2SC4738	SOT-523	NPN	100	150	60	50	5	120	700	6	2	0.25	100	10	80
2SC5585	SOT-523	NPN	150	500	15	12	6	270	680	2	10	0.25	200	10	320
BC847T	SOT-523	NPN	150	100	50	45	6	110	800	5	2	0.6	100	5	100
BC857T	SOT-523	PNP	150	100	50	45	6	125	800	5	2	0.65	100	5	100
MMBT2222AT	SOT-523	NPN	150	600	75	40	6	100	300	10	150	1	500	50	300
MMBT2907AT	SOT-523	PNP	150	600	60	60	5	100	300	10	150	1.6	500	50	200
MMBT3904T	SOT-523	NPN	150	200	60	40	6	100	300	1	10	0.3	50	5	300
MMBT3906T	SOT-523	PNP	150	200	40	40	5	100	300	1	10	0.4	50	5	250
CJ2515	SOT-523	NPN	150	1000	15	15	6	150	500	2	100	0.25	500	50	250
CJ3515	SOT-523	PNP	150	1000	15	15	6	150	500	2	100	0.25	500	50	100
2SA2029	SOT-723	BEC	150	150	60	50	6	120	560	6	1	0.5	50	5	140
2SC5658	SOT-723	BEC	100	150	60	50	7	120	560	6	1	0.4	50	5	180
2SC5663	SOT-723	BEC	150	500	15	12	6	270	680	2	10	0.25	200	10	320
MMBT2222AM	SOT-723	BEC	100	500	75	40	6	100	300	10	150	1	500	50	300
MMBT3904M	SOT-723	BEC	100	200	60	40	6	100	300	1	10	0.3	50	5	300
MMBT3906M	SOT-723	BEC	100	200	40	40	5	100	300	1	10	0.3	50	5	250
2SA1013	SOT-89	BCE	500	1000	160	160	6	60	320	5	200	1.5	500	50	15
2SA1201	SOT-89	BCE	500	800	120	120	5	80	240	5	100	1	500	50	120
2SA1203	SOT-89	BCE	500	1500	30	30	5	100	320	2	500	2	1500	30	120
2SA1204	SOT-89	BCE	500	800	35	30	5	100	320	1	100	0.7	500	20	120
2SA1213	SOT-89	BCE	500	2000	50	50	5	70	240	2	500	0.5	1000	50	100
2SA1661	SOT-89	BCE	500	800	120	120	5	80	240	5	100	1	500	50	120
2SA1662	SOT-89	BCE	500	400	80	80	5	70	240	2	50	0.4	200	20	120
2SA1664	SOT-89	BCE	500	800	35	30	5	100	320	1	100	0.7	500	20	120
2SA1740	SOT-89	BCE	500	200	400	400	5	60	200	10	50	0.6	50	5	70
2SA1797	SOT-89	BCE	500	2000	50	50	6	82	390	2	500	0.35	1000	50	200
2SB1073	SOT-89	BCE	500	4000	30	20	7	120	315	2	2000	1	3000	100	120
2SB1119	SOT-89	BCE	500	1000	25	25	5	100	560	2	50	0.7	500	50	180
2SB1132	SOT-89	BCE	500	1000	40	32	5	82	390	3	100	0.5	500	50	150
2SB1188	SOT-89	BCE	500	2000	40	32	5	82	390	3	500	0.8	2000	200	100
2SB1189	SOT-89	BCE	500	700	80	80	5	82	390	3	100	0.4	500	50	100
2SB1260	SOT-89	BCE	500	1000	80	80	5	82	390	3	100	0.4	500	50	100
2SB1308	SOT-89	BCE	500	3000	30	20	6	82	390	2	500	0.45	1500	150	120
2SB1386	SOT-89	BCE	500	5000	30	20	6	82	390	2	500	1	4000	100	120
2SB1424	SOT-89	BCE	500	3000	20	20	6	120	390	2	100	0.5	200	100	240
2SB1440	SOT-89	BCE	500	2000	50	50	5	120	340	2	200	0.3	1000	50	80
2SB766	SOT-89	BCE	500	1000	30	25	5	85	340	10	500	0.4	500	50	200
2SB766A	SOT-89	BCE	500	1000	60	50	5	85	340	10	500	0.4	500	50	200
2SC1766	SOT-89	BCE	500	2000	50	50	5	82	390	2	500	0.5	1000	50	120
2SC2383	SOT-89	BCE	500	1000	160	160	6	100	320	5	200	1	500	50	20
2SC2873	SOT-89	BCE	500	2000	50	50	5	70	240	2	500	0.5	1000	50	120
2SC2881	SOT-89	BCE	500	800	120	120	5	80	240	5	100	1	500	50	120
2SC2883	SOT-89	BCE	500	1500	30	30	5	100	320	2	500	2	1500	30	120
2SC2884	SOT-89	BCE	500	800	35	30	5	100	320	1	100	0.5	500	20	120
2SC3650	SOT-89	BCE	500	1200	30	25	15	800	3200	5	500	0.5	500	10	220
2SC4115	SOT-89	BCE	500	3000	40	20	6	120	560	2	100	0.5	2000	100	290
2SC4272	SOT-89	BCE	500	1000	75	45	5	60	320	5	500	0.6	500	50	180
2SC4373	SOT-89	BCE	500	800	120	120	5	80	240	5	100	1	500	50	120
2SC4374	SOT-89	BCE	500	400	80	80	5	70	240	2	50	0.4	200	20	100
2SC4375	SOT-89	BCE	500	1500	30	30	5	100	320	2	500	2	1500	30	120
2SC4548	SOT-89	BCE	500	200	400	400	5	60	200	10	50	0.6	50	5	70
2SC4672	SOT-89	BCE	500	2000	60	50	6	82	390	2	500	0.35	1000	50	210
2SC5785	SOT-89	BCE	500	2000	20	10	7	400	1000	2	200	0.12	600	12
2SD1005	SOT-89	BCE	500	1000	100	80	5	90	400	2	100	0.5	500	50	160
2SD1119	SOT-89	BCE	500	3000	40	25	7	230	600	2	500	1	3000	100	150
2SD1616A	SOT-89	BCE	500	1000	120	60	6	135	600	2	100	0.3	1000	50	100
2SD1664	SOT-89	BCE	500	1000	40	32	5	82	390	3	100	0.4	500	50	150
2SD1766	SOT-89	BCE	500	2000	40	32	5	82	390	3	500	0.8	2000	200	100
2SD1767	SOT-89	BCE	500	700	80	80	5	82	390	3	100	0.4	500	50	120
2SD1898	SOT-89	BCE	500	1000	100	80	5	82	390	3	500	0.4	500	20	100
2SD2098	SOT-89	BCE	500	5000	50	20	6	120	390	2	500	1	4000	100	150
2SD2150	SOT-89	BCE	500	3000	40	20	6	180	560	2	100	0.5	2000	100	290
2SD2153	SOT-89	BCE	500	2000	30	25	6	560	2700	6	500	0.5	1000	20	110
2SD2391	SOT-89	BCE	500	2000	60	60	6	120	270	2	500	0.35	1000	50	210
2SD2413	SOT-89	BCE	500	100	400	400	5	30		5	30	1.5	50	5	40
2SD874	SOT-89	BCE	500	1000	30	25	5	85	340	10	500	0.4	500	50	200
2SD874A	SOT-89	BCE	500	1000	60	50	5	85	340	10	500	0.4	500	50	200
2SD965	SOT-89	BCE	750	5000	40	20	7	230	800	2	500	1	3000	100	150
2SD965A	SOT-89	BCE	750	5000	40	30	7	230	800	2	500	1	3000	100	150
2SD999	SOT-89	BCE	500	1000	30	25	5	90	400	1	100	0.4	1000	100	130
A42	SOT-89	BCE	500	500	310	305	5	100	300	10	10	0.2	20	2	50
A44	SOT-89	BCE	500	300	400	400	6	50	200	10	10	0.75	50	5
A92	SOT-89	BCE	500	500	310	305	5	100	300	10	10	0.2	20	2	50
A94	SOT-89	BCE	500	300	400	400	5	80	300	10	10	0.3	50	5	50
B772	SOT-89	BCE	500	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
BC868	SOT-89	BCE	500	1000	32	20	5	85	375	1	500	0.5	1000	100	40
BC869	SOT-89	BCE	500	1000	32	20	5	100	375	1	500	0.5	1000	100	40
BCX51	SOT-89	BCE	500	1000	45	45	5	63	250	2	150	0.5	500	50	50
BCX52	SOT-89	BCE	500	1000	60	60	5	63	250	2	150	0.5	500	50	50
BCX53	SOT-89	BCE	500	1000	100	80	5	63	250	2	150	0.5	500	50	50
BCX54	SOT-89	BCE	500	1000	45	45	5	63	250	2	150	0.5	500	50	130
BCX55	SOT-89	BCE	500	1000	60	60	5	63	250	2	150	0.5	500	50	130
BCX56	SOT-89	BCE	500	1000	100	80	5	63	250	2	150	0.5	500	50	130
BCX69	SOT-89	BCE	800	1000	25	20	5	85	375	1	500	0.5	1000	100	100
BF620	SOT-89	BCE	500	50	300	300	5	50		20	25	0.6	30	5	60
BF622	SOT-89	BCE	500	50	250	250	5	50		20	25	0.6	30	5	60
BSR33	SOT-89	BCE	500	1000	90	80	5	100	300	5	100	0.5	500	50	100
BSR43	SOT-89	BCE	500	1000	90	80	5	100	300	5	100	0.5	500	50	100
BST39	SOT-89	BCE	500	100	400	350	5	40+		10	20	0.5	50	4	70
BST40	SOT-89	BCE	500	100	300	250	5	40+		10	20	0.5	50	4	70
CJ303PL	SOT-89	BCE	500	3000	30	30	5	100	400	1.5	1500	0.4	3000	100	100
CJF715	SOT-89	BCE	500	1500	140	80	5	80		2	500	0.5	1000	100	50
CXT5401	SOT-89	BCE	500	500	160	150	5	60	300	5	10	0.5	50	5	100
CXT5551	SOT-89	BCE	500	600	180	160	6	80	300	5	10	0.2	50	5	100
D882	SOT-89	BCE	500	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
FCX591	SOT-89	BCE	500	1000	80	60	5	100	300	5	500	0.6	1000	100	150
HM4033	SOT-89	BCE	500	1000	80	80	5	100		5	100	0.5	500	50	100
HM879	SOT-89	BCE	500	3000	30	10	6	140		2	3000	0.4	3000	60	200
KTA1273	SOT-89	BCE	500	2000	30	30	5	100	320	2	500	2	1500	30	120
KTA1663	SOT-89	BCE	500	1500	30	30	5	100	320	2	500	2	1500	30	120
KTA1664	SOT-89	BCE	500	800	35	30	5	100	320	1	100	0.7	500	20	120
KTA1666	SOT-89	BCE	500	2000	50	50	5	70	240	2	500	0.5	1000	50	120
KTA1668	SOT-89	BCE	500	1000	80	60	5	60	320	2	50	0.7	500	50	150
KTC3205	SOT-89	BCE	500	2000	30	30	5	100	320	2	500	2	1500	30	120
KTC4372	SOT-89	BCE	500	50	200	150	5	70	240	5	10	0.5	10	1	120
KTC4373	SOT-89	BCE	500	800	120	120	5	80	240	5	100	1	500	50	120
KTC4374	SOT-89	BCE	500	400	80	80	5	70	240	2	50	0.4	200	20	100
KTC4375	SOT-89	BCE	500	1500	30	30	5	100	320	2	500	2	1500	30	120
KTC4376	SOT-89	BCE	500	800	35	30	5	100	320	1	100	0.5	500	20	120
KTC4377	SOT-89	BCE	500	2000	30	10	6	140	600	1	500	0.5	2000	50	150
KTC4378	SOT-89	BCE	500	1000	80	60	5	100	320	2	50	0.5	500	50	150
KTC4379	SOT-89	BCE	500	2000	50	50	5	70	240	2	500	0.5	1000	50	120
KTD1302	SOT-89	BCE	500	300	25	20	12	200	800	2	4	0.25	100	10	60
KTD1898	SOT-89	BCE	500	1000	100	80	5	70	400	3	500	0.4	500	20	100
PXT2222A	SOT-89	BCE	500	600	75	40	6	100	300	10	150	1	500	50	300
PXT2907A	SOT-89	BCE	500	600	60	60	5	100	300	10	150	1.6	500	50	200
PXT3904	SOT-89	BCE	500	200	60	40	6	100	300	1	10	0.3	50	5	300
PXT3906	SOT-89	BCE	500	200	40	40	6	100	300	1	10	0.4	50	5	250
PXT8050	SOT-89	BCE	500	1500	40	25	5	85	400	1	100	0.5	800	80	100
PXT8550	SOT-89	BCE	500	1500	40	25	5	85	400	1	100	0.5	800	80	100
D882H	SOT-89	BCE	500	3000	70	70	6	60	400	2	1000	0.5	2000	200	50
B772	SOT-223	PNP	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
BCP51	SOT-223	PNP	1500	1000	45	45	5	63	250	2	150	0.5	500	50	100
BCP52	SOT-223	PNP	1500	1000	60	60	5	63	250	2	150	0.5	500	50	100
BCP53	SOT-223	PNP	1500	1000	100	80	5	63	250	2	150	0.5	500	50	100
BCP54	SOT-223	NPN	1500	1000	45	45	5	63	250	2	150	0.5	500	50	100
BCP55	SOT-223	NPN	1500	1000	60	60	5	63	250	2	150	0.5	500	50	100
BCP56	SOT-223	NPN	1500	1000	100	80	5	63	250	2	150	0.5	500	50	100
BCP68	SOT-223	NPN	1000	1000	32	20	5	85	375	1	500	0.5	1000	100	40
BCP69	SOT-223	PNP	1000	1000	32	20	5	85	375	1	500	0.5	1000	100	40
CZT31C	SOT-223	NPN	1000	3000	100	100	5	10	100	4	3000	1.2	3000	375	3
CZT32C	SOT-223	PNP	1000	3000	100	100	5	10	100	4	3000	1.2	3000	375	3
CZT5401	SOT-223	PNP	1000	600	160	150	5	60	300	5	10	0.5	50	5	100
CZT5551	SOT-223	NPN	1000	600	180	160	6	80	250	5	10	0.2	50	5	100
PZT2222A	SOT-223	NPN	1000	600	75	40	6	100	300	10	150	1	500	50	300
PZT2907A	SOT-223	PNP	1000	600	60	60	5	100	300	10	150	1.6	500	50	200
PZT3904	SOT-223	NPN	1000	200	60	40	6	100	300	1	10	0.2	50	5	300
PZT3906	SOT-223	PNP	1000	200	40	40	5	100	300	1	10	0.4	50	5	250
PZT4401	SOT-223	NPN	1000	600	60	40	6	100	300	1	150	0.75	500	50	250
PZT4403	SOT-223	PNP	1000	600	40	40	6	100	300	1	150	0.75	500	50	200
PZTA06	SOT-223	NPN	1000	500	80	80	4	100		1	10	0.25	100	10	100
PZTA42	SOT-223	NPN	1000	500	300	300	6	40		10	10	0.5	20	2	50
PZTA44	SOT-223	NPN	1000	300	400	400	6	50	200	10	10	0.75	50	5	20
PZTA56	SOT-223	PNP	1000	500	80	80	4	100		1	10	0.25	100	10	50
PZTA92	SOT-223	PNP	1000	500	300	300	5	25		10	10	0.5	20	2	50
PZTA94	SOT-223	PNP	1000	300	400	400	5	80	300	10	10	0.3	50	5	50
D882	SOT-223	NPN	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
FZT692B	SOT-223	NPN	800	4500	70	70	5	400		2	500	0.5	2000	200	10
FZT955	SOT-223	PNP	800	4000	180	140	6	100	300	5	1000	0.37	3000	300	30
2N3828	TO-92	NPN	300	100	40	40	3	30	200	1	12	0.3	50	5	360
2N3904	TO-92	NPN	625	200	60	40	6	100	400	1	10	0.3	50	5	300
2N3906	TO-92	PNP	625	200	40	40	5	100	400	1	10	0.4	50	5	250
2N4124	TO-92	NPN	350	200	30	25	5	120	360	1	2	0.3	50	5	300
2N4126	TO-92	PNP	625	200	25	25	4	120	360	1	2	0.4	50	5	250
2N4400	TO-92	NPN	625	600	60	40	6	50	150	1	150	0.75	500	50	200
2N4401	TO-92	NPN	625	600	60	40	6	100	300	1	150	0.75	500	50	250
2N4402	TO-92	PNP	625	600	40	40	5	50	150	2	150	0.75	500	50	150
2N4403	TO-92	PNP	625	600	40	40	5	100	300	1	150	0.75	500	50	200
2N5087	TO-92	PNP	625	50	50	50	3	250	800	5	0.1	0.3	10	1	40
2N5172	TO-92	NPN	625	500	25	25	5	100	500	10	10	0.25	10	1
2N5400	TO-92	PNP	625	600	130	120	5	40	180	5	10	0.5	50	5	100
2N5401	TO-92	PNP	625	600	160	150	5	60	300	5	10	0.5	50	5	100
2N5550	TO-92	NPN	625	600	160	140	6	60	250	5	10	0.25	50	5	100
2N5551	TO-92	NPN	625	600	180	160	6	80	300	5	10	0.2	50	5	100
2N5551K	TO-92	NPN	625	600	180	160	6	80	300	5	10	0.2	50	5	100
2N5832	TO-92	NPN	625	600	160	140	5	175	500	5	10	0.25	50	5	100
2N6517	TO-92	NPN	625	500	350	350	6	30	200	10	30	1	50	5	40
2N6520	TO-92	PNP	625	500	350	350	5	30	200	10	30	1	50	5	40
2N6718	TO-92	NPN	625	1000	100	100	5	50	250	1	250	0.35	250	25	50
2N6727	TO-92	PNP	1000	1500	50	40	5	50	250	1	1000	0.5	1000	100	50
2SA1015	TO-92	PNP	400	150	50	50	5	70	400	6	2	0.3	100	10	80
2SA1048	TO-92	PNP	200	150	50	50	5	70	400	6	2	0.3	100	10	80
2SA1081	TO-92	PNP	400	100	90	90	5	250	800	12	2	0.2	10	1	90
2SA1082	TO-92	PNP	400	100	120	120	5	250	800	12	2	0.2	10	1	90
2SA1083	TO-92	PNP	400	100	60	60	5	250	800	12	2	0.2	10	1	90
2SA1084	TO-92	PNP	400	100	90	90	5	250	800	12	2	0.2	10	1	90
2SA1296	TO-92	PNP	750	2000	20	20	6	120	400	2	100	0.5	2000	100	120
2SA1300	TO-92	PNP	750	2000	20	10	6	140	600	1	500	0.82	2000	100	140
2SA1318	TO-92	PNP	500	200	60	50	6	100	560	6	1	0.3	100	10	200
2SA1515	TO-92	PNP	500	1000	40	32	5	82	390	3	100	0.5	500	50	50
2SA1625	TO-92	PNP	750	500	400	400	7	40	200	5	50	0.5	100	10	20
2SA1980	TO-92	PNP	625	150	50	50	5	70	700	6	2	0.3	100	10	80
2SA1981	TO-92	PNP	625	800	35	30	5	100	320	1	100	0.5	500	20	120
2SA562	TO-92	PNP	500	500	35	30	5	70	240	1	100	0.25	100	10	200
2SA608N	TO-92	PNP	500	150	60	50	6	160	560	6	1	0.3	100	10	200
2SA673	TO-92	PNP	400	500	35	35	4	60	320	3	10	0.6	150	15
2SA673A	TO-92	PNP	400	500	50	50	4	60	320	3	10	0.6	150	15
2SA719	TO-92	PNP	625	500	30	25	5	85	340	10	150	0.6	300	30	200
2SA720	TO-92	PNP	625	500	60	50	5	85	340	10	150	0.6	300	30	200
2SA821	TO-92	PNP	250	30	210	210	5	56	270	3	5	0.6	2	0.2	50
2SA836	TO-92	PNP	200	100	55	55	5	160	500	12	2	0.5	10	1	150
2SA844	TO-92	PNP	300	100	55	55	5	160	800	12	2	0.5	10	1	200
2SA950	TO-92	PNP	600	800	35	30	5	100	320	1	100	0.7	500	20	120
2SB1068	TO-92	PNP	625	2000	20	16	6	135	650	2	100	0.5	1500	75	100
2SB1116	TO-92	PNP	750	1000	60	50	6	135	600	2	100	0.3	1000	50	70
2SB1116A	TO-92	PNP	750	1000	80	60	6	135	600	2	100	0.3	1000	50	70
2SB1322A	TO-92	PNP	625	1000	60	50	5	85	340	10	500	0.4	500	50	200
2SB1426	TO-92	PNP	750	3000	20	20	6	82	390	2	100	0.5	2000	100	240
2SB561	TO-92	PNP	500	700	25	20	5	85	240	1	150	0.5	500	50	350
2SB562	TO-92	PNP	625	1000	25	20	5	85	240	2	500	0.5	800	80	350
2SC1008	TO-92	NPN	800	700	80	60	8	40	400	2	50	0.4	500	50	30
2SC1213	TO-92	NPN	400	500	35	35	4	60	320	3	10	0.6	150	15
2SC1213A	TO-92	NPN	400	500	50	50	4	60	320	3	10	0.6	150	15
2SC1318	TO-92	NPN	625	500	60	50	7	85	340	10	150	0.6	300	30	200
2SC1318A	TO-92	NPN	750	500	80	70	5	85	340	10	150	0.6	300	30	120
2SC1359	TO-92	NPN	400	30	30	20	5	70	220	10	1	0.2	15	1.5	150
2SC1674	TO-92	NPN	250	20	30	20	4	40	180	6	1	0.3	10	1	400
2SC1675	TO-92	NPN	625	50	50	30	5	40	240	6	1	0.3	10	1	150
2SC1815	TO-92	NPN	400	150	60	50	5	70	700	6	2	0.25	100	10	80
2SC1923	TO-92	NPN	100	20	40	30	4	40	200	6	1				550
2SC1959	TO-92	NPN	500	500	35	30	5	70	400	1	100	0.25	100	10	300
2SC2001	TO-92	NPN	600	700	30	25	5	90	400	1	100	0.6	700	70	50
2SC2120	TO-92	NPN	600	800	35	30	5	100	320	1	100	0.5	500	20	100
2SC2130	TO-92	NPN	600	800	45	40	5	100	320	1	100	0.5	500	20	100
2SC2216	TO-92	NPN	300	50	50	45	4	40	140	12.5	12.5	0.2	15	1.5	300
2SC2274	TO-92	NPN	600	500	60	50	5	60	320	5	50	0.6	400	40	120
2SC2551	TO-92	NPN	400	100	300	300	6	30	150	10	20	0.5	20	2	80
2SC2717	TO-92	NPN	300	50	30	25	4	90	320	12.5	12.5	0.2	15	1.5	300
2SC2878A	TO-92	NPN	400	300	50	20	15	200	1200	2	4	0.3	30	3	30
2SC3199	TO-92	NPN	400	150	50	50	5	70	700	6	2	0.25	100	10	80
2SC3279	TO-92	NPN	750	2000	30	10	6	140	600	1	500	0.82	2000	100	150
2SC3415	TO-92	NPN	500	100	300	300	5	39	180	10	10	2	50	5	50
2SC380TM	TO-92	NPN	300	50	35	30	4	40	240	12	2	0.4	10	1	100
2SC388	TO-92	NPN	300	50	30	25	4	20	200	12.5	12.5	0.2	15	1.5	300
2SC5343	TO-92	NPN	625	150	60	50	5	70	700	6	2	0.25	100	10	80
2SC5344	TO-92	NPN	625	800	35	30	5	100	320	1	100	0.5	500	50	120
2SC5345	TO-92	NPN	625	20	30	20	4	40	240	6	1	0.3	10	1	550
2SC536	TO-92	NPN	400	100	40	30	5	60	960	6	1	0.5	50	5	100
2SC536N	TO-92	NPN	625	150	60	50	6	160	560	6	1	0.3	100	10	200
2SD1468	TO-92	NPN	625	1000	30	15	5	120	560	3	100	0.4	500	50	50
2SD1513	TO-92	NPN	625	2000	20	16	6	135	650	2	100	0.4	1000	10	100
2SD1616	TO-92	NPN	750	1000	60	50	6	135	600	2	100	0.3	1000	50	100
2SD1616A	TO-92	NPN	750	1000	120	60	6	135	600	2	100	0.3	1000	50	100
2SD1835	TO-92	NPN	750	2000	60	50	6	100	560	2	100	0.4	1000	50	150
2SD1991A	TO-92	NPN	400	100	60	50	7	160	460	10	2	0.3	100	10	150
2SD1994A	TO-92	NPN	625	1000	60	50	5	85	340	10	500	0.4	500	50	200
2SD2097	TO-92	NPN	625	5000	50	20	6	120	390	2	500	1	4000	100	150
2SD2152	TO-92	NPN	700	3000	22	22	6	180	950	2	100	0.4	2000	100	150
2SD879	TO-92	NPN	750	3000	30	10	6	140		2	3000	0.4	3000	60	200
3DG3332	TO-92	NPN	625	700	180	160	6	100	400	5	100	0.4	250	25	120
8050S	TO-92	NPN	625	500	40	25	5	85	400	1	50	0.6	500	50	150
8050SS	TO-92	NPN	1000	1500	40	25	5	85	300	1	100	0.5	800	80	100
8550S	TO-92	PNP	625	500	40	25	5	85	400	1	50	0.6	500	50	150
8550SS	TO-92	PNP	1000	1500	40	25	5	85	300	1	100	0.5	800	80	100
9012S	TO-92	PNP	625	500	40	25	5	64	400	1	50	0.6	500	50	150
9013S	TO-92	NPN	625	500	40	25	5	64	400	1	50	0.6	500	50	150
A1015	TO-92	PNP	400	150	50	50	5	70	400	6	2	0.3	100	10	80
A42	TO-92	NPN	625	500	310	305	5	80	250	10	10	0.2	20	2	50
A44	TO-92	NPN	625	200	400	400	5	80	300	10	10	0.3	50	5	50
A733	TO-92	PNP	250	100	60	50	5	90	600	6	1	0.3	100	10	100
A92	TO-92	PNP	625	500	310	305	5	80	250	10	10	0.2	20	2	50
A94	TO-92	PNP	625	200	400	400	5	80	300	10	10	0.3	50	5	50
B772S	TO-92	PNP	625	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
BC212	TO-92	PNP	350	100	60	50	5	140	600	5	2	0.6	100	5	200
BC237	TO-92	NPN	350	100	50	45	6	120	800	5	2	0.6	100	5	100
BC238	TO-92	NPN	350	100	30	25	5	200	800	5	2	0.8	100	5	120
BC307	TO-92	PNP	500	100	50	45	5	120	800	5	2	0.6	100	5	130
BC308	TO-92	PNP	500	100	30	25	5	120	800	5	2	0.6	100	5	130
BC309	TO-92	PNP	500	100	30	25	5	120	800	5	2	0.6	100	5	130
BC327	TO-92	PNP	625	800	50	45	5	100	630	1	100	0.7	500	50	260
BC328	TO-92	PNP	625	800	30	25	5	100	630	1	100	0.7	500	50	260
BC337	TO-92	NPN	625	800	50	45	5	100	630	1	100	0.7	500	50	210
BC338	TO-92	NPN	625	800	30	25	5	100	630	1	100	0.7	500	50	210
BC347	TO-92	NPN	300	100	50	45	5	40	450	5	2	0.3	10	1	125
BC350	TO-92	PNP	300	100	50	45	5	40	450	5	2	0.3	10	1	125
BC368	TO-92	NPN	625	1000	25	20	5	85	375	1	500	0.5	1000	100	65
BC369	TO-92	PNP	625	1000	25	20	5	85	375	1	500	0.5	1000	100	65
BC546	TO-92	NPN	625	100	80	65	6	110	800	5	2	0.3	100	5	150
BC547	TO-92	NPN	625	100	50	45	6	110	800	5	2	0.3	100	5	150
BC548	TO-92	NPN	625	100	30	30	5	110	800	5	2	0.3	100	5	150
BC556	TO-92	PNP	625	100	80	65	5	120	800	5	2	0.65	100	5	150
BC557	TO-92	PNP	625	100	50	45	5	120	800	5	2	0.65	100	5	150
BC558	TO-92	PNP	625	100	30	30	5	120	800	5	2	0.65	100	5	150
BC635	TO-92	NPN	830	1000	45	45	5	40	250	2	150	0.5	500	50	100
BC636	TO-92	PNP	830	1000	45	45	5	63	250	2	150	0.5	500	50	100
BC637	TO-92	NPN	830	1000	60	60	5	63	250	2	150	0.5	500	50	100
BC638	TO-92	PNP	830	1000	60	60	5	63	250	2	150	0.5	500	50	100
BC639	TO-92	NPN	830	1000	100	80	5	63	250	2	150	0.5	500	50	100
BC640	TO-92	PNP	830	1000	100	80	5	63	250	2	150	0.5	500	50	100
BF240	TO-92	NPN	300	25	40	40	4	67	220	10	1	0.3	10	1	150
BF370	TO-92	NPN	500	100	40	15	4.5	40	200	1	10	0.2	15	1.5	500
BF420	TO-92	NPN	830	100	300	300	5	50		20	25	0.6	30	5	60
BF421	TO-92	PNP	830	100	300	300	5	50		20	25	0.6	20	2	60
BF422	TO-92	NPN	830	100	250	250	5	50		20	25	0.6	30	5	60
BF423	TO-92	PNP	830	100	250	250	5	50		20	25	0.6	30	5	60
BF483	TO-92	NPN	830	100	300	250	5	20		20	40	0.6	30	5	70
BF485	TO-92	NPN	830	100	350	300	5	20		20	40	0.6	30	5	70
BF487	TO-92	NPN	830	100	400	350	5	20		20	40	0.6	30	5	70
C1815	TO-92	NPN	400	150	60	50	5	70	700	6	2	0.25	100	10	80
C945	TO-92	NPN	400	150	60	50	5	70	700	6	1	0.3	100	10	200
D882S	TO-92	NPN	625	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
D965	TO-92	NPN	750	5000	42	22	6	340	2000	2	500	0.35	3000	100	150
D965V	TO-92	NPN	750	5000	22	15	6	1200	2000	2	500	0.35	3000	100	150
KSA539	TO-92	PNP	400	200	60	45	5	40	240	1	50	0.5	150	15
KSA642	TO-92	PNP	400	300	30	25	5	70	400	1	50	0.6	300	30
KSA643	TO-92	PNP	500	500	40	20	5	40	400	1	100	0.4	500	50
KSA708	TO-92	PNP	800	700	80	60	8	40	240	2	50	0.7	500	50	50
KSB564A	TO-92	PNP	800	1000	30	25	5	70	400	1	100	0.5	1000	100	110
KSC1730	TO-92	NPN	200	50	30	15	5	40	240	10	5	0.5	10	1	800
KSC5019	TO-92	NPN	750	2000	30	10	6	140	600	1	500	0.5	2000	50	150
KSC815	TO-92	NPN	400	200	60	45	5	40	400	1	50	0.4	150	15	100
KSD471A	TO-92	NPN	800	1000	40	30	5	70	400	1	100	0.5	1000	100	130
KSD471A-R	TO-92	NPN	800	1000	40	30	5	70	400	1	100	0.5	1000	100	130
KTA1266	TO-92	PNP	625	150	50	50	5	70	400	6	2	0.3	100	10	80
KTA1270	TO-92	PNP	500	500	35	30	5	70	240	1	100	0.25	100	10	200
KTA1271	TO-92	PNP	625	800	35	30	5	100	320	1	100	0.7	500	20	120
KTC3192	TO-92	NPN	625	50	35	30	4	40	240	12	2	0.4	10	1	100
KTC3194	TO-92	NPN	625	20	40	30	4	40	200	6	1	0.2	15	1.5	550
KTC3197	TO-92	NPN	625	50	30	25	4	20	200	12.5	12.5	0.2	15	1.5	300
KTC3198	TO-92	NPN	625	150	60	50	5	70	700	6	2	0.25	100	10	80
KTC3202	TO-92	NPN	625	500	35	30	5	70	400	1	100	0.25	100	10	300
KTC3203	TO-92	NPN	625	800	35	30	5	100	320	1	100	0.5	500	20	120
KTD1146	TO-92	NPN	625	5000	40	20	7	120	700	2	500	0.4	3000	60	20
M28S	TO-92	NPN	625	1000	40	20	6	300	1000	1	100	0.55	600	20	100
M8050	TO-92	NPN	625	800	40	25	6	80	400	1	100	0.5	800	80	150
M8050S	TO-92	NPN	625	800	40	25	6	80	400	1	100	0.5	800	80	150
M8550	TO-92	PNP	625	800	40	25	6	80	400	1	100	0.5	800	80	150
M8550S	TO-92	PNP	625	800	40	25	6	80	400	1	100	0.5	800	80	150
MPS2222	TO-92	NPN	625	600	60	30	5	100	300	10	150	1	500	50	250
MPS2222A	TO-92	NPN	625	600	75	40	6	100	300	10	150	0.6	500	50	300
MPS2907	TO-92	PNP	625	600	60	40	5	100	300	10	150	0.67	500	50	200
MPS2907A	TO-92	PNP	625	600	60	60	5	100	300	10	150	0.67	500	50	200
MPS3702	TO-92	PNP	625	800	40	25	5	60	300	5	50	0.25	50	5	100
MPS651	TO-92	NPN	625	2000	80	60	5	75		2	1000	0.5	2000	200	75
MPS750	TO-92	PNP	625	2000	60	40	5	75	400	2	500	0.3	1000	100	75
MPSA05	TO-92	NPN	625	500	60	60	4	100		1	10	0.25	100	10	100
MPSA06	TO-92	NPN	625	500	80	80	4	100	400	1	100	0.25	100	10	100
MPSA17	TO-92	NPN	300	100		40	12	200	800	10	5	0.25	10	1	80
MPSA43	TO-92	NPN	625	200	200	200	6	40	200	10	10	0.4	20	2	50
MPSA44	TO-92	NPN	625	300	400	400	6	50	200	10	10	0.75	50	5
MPSA55	TO-92	PNP	625	500	60	60	4	100		1	10	0.25	100	10
MPSA56	TO-92	PNP	625	500	80	80	4	100		1	10	0.25	100	10	50
MPSA93	TO-92	PNP	625	500	200	200	5	40		10	10	0.4	20	2	50
MPSH10/11	TO-92	NPN	350	40	30	25	3	60		10	4	0.5	4	0.4	650
MPSL51	TO-92	PNP	625	200	100	100	4	40	250	5	50	0.3	50	5	60
MPSW51	TO-92	PNP	625	1000	40	30	5	60		1	100	0.7	1000	100	50
PH2369	TO-92	NPN	500	200	40	15	4.5	40	120	1	10	0.25	10	1	500
S8050	TO-92	NPN	625	500	40	25	5	85	400	1	50	0.6	500	50	150
S8550	TO-92	PNP	625	500	40	25	5	85	400	1	50	0.6	500	50	150
S9012	TO-92	PNP	625	500	40	25	5	64	400	1	50	0.6	500	50	150
S9013	TO-92	NPN	625	500	40	25	5	64	400	1	50	0.6	500	50	150
S9014	TO-92	NPN	450	100	50	45	5	60	1000	5	1	0.3	100	5	150
S9015	TO-92	PNP	450	100	50	45	5	60	1000	5	1	0.3	100	10	100
S9018	TO-92	NPN	400	50	25	18	4	28	270	5	1	0.5	10	1	800
SS8050	TO-92	NPN	1000	1500	40	25	5	85	400	1	100	0.5	800	80	100
SS8550	TO-92	PNP	1000	1500	40	25	5	85	400	1	100	0.5	800	80	100
STA124	TO-92	PNP	625	1000	15	12	6.5	200	450	1	100	0.4	500	50	260
STB1277	TO-92	PNP	625	2000	30	30	5	100	320	2	500	0.8	2000	200	170
STC128	TO-92	NPN	625	1000	20	15	6.5	150		1	100	0.3	500	50	260
TSC1417	TO-92	NPN	625	30	20	15	3	29	270	6	1	0.5	10	1	300
2SA1020	TO-92	PNP	625	2000	50	50	5	70	240	2	500	0.5	1000	50	100
2SA952	TO-92	PNP	600	700	30	25	5	90	400	1	100	0.6	700	70	50
2SA1048	TO-92S	PNP	200	150	50	50	5	70	400	6	2	0.3	100	10	80
2SA1267	TO-92S	PNP	400	150	50	50	5	70	700	6	2	0.25	100	10	80
2SA1309A	TO-92S	PNP	300	100	60	50	7	160	460	10	2	0.3	50	5	80
2SA1317	TO-92S	PNP	300	200	60	50	6	100	560	6	1	0.3	100	10	200
2SA1515S	TO-92S	PNP	300	1000	40	32	5	82	390	3	100	0.5	500	50	50
2SA1585S	TO-92S	PNP	400	2000	20	20	6	120	560	2	100	0.5	2000	100	240
2SA608S	TO-92S	PNP	300	100	40	30	5	60	560	6	1	0.5	50	5	180
2SA821S	TO-92S	PNP	250	30	210	210	5	56	270	3	5	0.6	2	0.2	50
2SA854S	TO-92S	PNP	200	500	40	32	5	120	390	3	10	0.4	100	10	200
2SA933AS	TO-92S	PNP	300	150	60	50	6	120	560	6	1	0.5	50	5	140
2SC1740S	TO-92S	NPN	300	150	60	50	7	120	560	6	1	0.4	50	5	100
2SC1741S	TO-92S	NPN	200	500	40	32	5	120	560	3	100	0.4	500	50	250
2SC1959	TO-92S	NPN	500	500	35	30	5	70	400	1	100	0.25	100	10	300
2SC2389S	TO-92S	NPN	300	50	120	120	5	180	560	6	2	0.5	10	1	140
2SC2458	TO-92S	NPN	200	150	50	50	5	70	700	6	2	0.25	100	10	80
2SC2668	TO-92S	NPN	200	20	40	30	4	40	200	6	1				550
2SC2785	TO-92S	NPN	250	100	60	50	5	110	600	6	1	0.3	100	10	150
2SC2839	TO-92S	NPN	400	30	30	20	5	60	320	6	1				200
2SC2999	TO-92S	NPN	400	30	25	20	3	40	200	6	1				450
2SC3199	TO-92S	NPN	400	150	50	50	5	70	700	6	2	0.25	100	10	80
2SC3311A	TO-92S	NPN	300	100	60	50	7	160	460	10	2	0.3	100	10	150
2SC3330	TO-92S	NPN	300	200	60	50	6	100	800	6	1	0.3	100	10	200
2SC4115S	TO-92S	NPN	300	3000	40	20	6	120	560	2	100	0.5	2000	100	290
2SC536S	TO-92S	NPN	300	100	40	30	5	60	960	6	1	0.5	50	5	100
2SD1468S	TO-92S	NPN	300	1000	30	15	5	120	560	3	100	0.4	500	50	50
2SD2470	TO-92S	NPN	400	5000	15	10	8	270	820	2	2000	0.5	3000	100	170
KSA1150	TO-92S	PNP	300	500	40	20	5	40	400	1	100	0.4	500	50	150
KSA1175	TO-92S	PNP	250	150	60	50	5	40	700	6	1	0.3	100	10	50
KSB811	TO-92S	PNP	350	1000	30	25	5	70	400	1	100	0.5	1000	100	110
KSC2785	TO-92S	NPN	250	150	60	50	5	70	700	6	1	0.3	100	10	300
KSD1020	TO-92S	NPN	350	700	30	25	5	120	400	1	100	0.4	700	70	50
KSD1021	TO-92S	NPN	350	1000	40	30	5	70	400	1	100	0.5	1000	100	130
KTA1267	TO-92S	PNP	400	150	50	50	5	70	400	6	2	0.3	100	10	80
KTA1297	TO-92S	PNP	400	2000	20	20	6	120	400	2	100	0.5	2000	100	120
KTC3195	TO-92S	NPN	400	20	40	30	4	40	200	6	1				300
KTC3199	TO-92S	NPN	400	150	50	50	5	70	700	6	2	0.25	100	10	80
STC128	TO-92S	NPN	400	1000	20	15	6.5	150		1	100	0.3	500	50	260
2SA1013	TO-92S	PNP	900	1000	160	160	6	60	320	5	200	1.5	500	50	15
2SA1020	TO-92S	PNP	900	2000	50	50	5	70	240	2	500	0.5	1000	50	100
2SA1160	TO-92S	PNP	900	2000	20	10	6	140	600	1	500	0.5	2000	50	140
2SA683	TO-92S	PNP	750	1000	30	25	5	85	340	10	500	0.4	500	50	200
2SA684	TO-92S	PNP	750	1000	60	50	5	85	340	10	500	0.4	500	50	200
2SA935	TO-92S	PNP	750	700	80	80	5	82	390	3	100	0.4	500	50	100
2SA966	TO-92S	PNP	900	1500	30	30	5	100	320	2	500	2	1500	30	120
2SB562	TO-92S	PNP	750	1000	25	20	5	85	240	2	500	0.5	800	80	350
2SB647	TO-92S	PNP	750	1000	120	80	5	60	320	5	150	1	500	50	140
2SB649	TO-92S	PNP	900	1500	180	120	5	60	320	5	150	1	500	50	140
2SB649A	TO-92S	PNP	900	1500	180	160	5	60	200	5	150	1	500	50	140
2SB764	TO-92S	PNP	750	1000	60	50	5	60	320	2	50	0.7	500	50	150
2SB892	TO-92S	PNP	750	2000	60	50	6	100	560	2	100	0.4	1000	50	150
2SC1383	TO-92S	NPN	750	1000	30	25	5	85	340	10	500	1.2	500	50	200
2SC1384	TO-92S	NPN	750	1000	60	50	5	85	340	10	500	1.2	500	50	200
2SC1627A	TO-92S	NPN	750	400	80	80	5	70	240	2	50	0.4	200	20	100
2SC2060	TO-92S	NPN	750	1000	40	32	5	80	400	3	100	0.4	500	50	50
2SC2230A	TO-92S	NPN	800	100	200	180	5	120	400	10	10	0.5	50	5	50
2SC2235	TO-92S	NPN	900	800	120	120	5	80	240	5	100	1	500	50	120
2SC2236	TO-92S	NPN	900	1500	30	30	5	100	320	2	500	2	1500	30	120
2SC2383	TO-92S	NPN	900	1000	160	160	6	60	320	5	200	1	500	50	20
2SC2482	TO-92S	NPN	900	100	300	300	7	30	150	10	20	1	10	1	50
2SC2500	TO-92S	NPN	900	2000	30	10	6	140	600	1	500	0.5	2000	50	150
2SC2655	TO-92S	NPN	900	2000	50	50	5	70	240	2	500	0.5	1000	50	100
2SC2703	TO-92S	NPN	750	1000	30	30	5	100	320	2	100	0.5	800	80	150
2SD400	TO-92S	NPN	750	1000	25	25	5	60	560	2	50	0.3	500	50	180
2SD468	TO-92S	NPN	750	1000	25	20	5	85	240	2	500	0.5	800	80	190
2SD667	TO-92S	NPN	900	1000	120	80	5	60	320	5	150	1	500	50	140
2SD667A	TO-92S	NPN	900	1000	120	100	5	60	320	5	150	1	500	50	140
2SD669A	TO-92S	NPN	750	1500	180	160	5	60	320	5	150	1	600	50	140
2SD789	TO-92S	NPN	750	1000	100	50	6	100	800	2	100	0.3	1000	100	100
3CG8551	TO-92S	PNP	750	2000	50	40	5	100	320	2	100	1	1000	100	150
3DG8051	TO-92S	NPN	750	2000	50	40	5	100	320	2	100	1	1000	100	150
KSA708	TO-92S	PNP	800	700	80	60	8	40	240	2	50	0.7	500	50	50
KSA916	TO-92S	PNP	900	800	120	120	5	80	240	5	100	1	500	50	120
KSA928A	TO-92S	PNP	750	2000	30	30	5	100	320	2	500	2	1500	30	120
KSA931	TO-92S	PNP	750	700	80	60	8	40	320	2	50	1.2	500	50	100
KSC2316	TO-92S	NPN	900	800	120	120	5	80	240	5	100	1	500	50	120
KSC2328A	TO-92S	NPN	750	2000	30	30	5	100	320	2	500	2	1500	30	120
KSC2330	TO-92S	NPN	750	100	300	300	7	40	240	10	20	0.5	10	1	50
KSC2331	TO-92S	NPN	750	700	80	60	8	40	240	2	50	0.7	500	50	30
KTA1023	TO-92S	PNP	900	800	120	120	5	80	240	5	100	1	500	50	120
KTA1024	TO-92S	PNP	750	50	150	150	5	70	240	5	10	0.8	10	1	120
KTA1241	TO-92S	PNP	900	5000	35	20	8	100	320	2	500	0.5	3000	75	170
KTA1273	TO-92S	PNP	750	2000	30	30	5	100	320	2	500	2	1500	30	120
KTA1274	TO-92S	PNP	750	400	80	80	5	70	240	2	50	0.4	200	20	100
KTA1275	TO-92S	PNP	900	1000	160	160	6	60	320	5	200	1.5	500	50	15
KTA1281	TO-92S	PNP	750	2000	50	50	5	70	240	2	500	0.5	1000	50	100
KTC1027	TO-92S	NPN	1000	800	120	120	5	80	240	5	100	1	500	50	120
KTC3205	TO-92S	NPN	750	2000	30	30	5	100	320	2	500	2	1500	30	120
KTC3206	TO-92S	NPN	1000	50	200	150	5	70	240	5	10	0.5	10	1	120
KTC3207	TO-92S	NPN	1000	100	300	300	7	30	150	10	20	1	10	1	50
KTC3227	TO-92S	NPN	1000	400	80	80	5	70	240	2	50	0.4	200	20	100
KTC3228	TO-92S	NPN	900	1000	160	160	6	60	320	5	200	1.5	500	50	20
KTD863	TO-92S	NPN	1000	1000	60	60	5	60	320	2	50	0.5	500	50	150
TPT5609	TO-92S	NPN	750	1000	25	20	5	60	240	2	500	0.5	800	80	190
TPT5610	TO-92S	PNP	1000	1000	25	20	5	60	240	2	500	0.5	800	80	350
2SA1013	TO-92MOD	PNP	900	1000	160	160	6	60	320	5	200	1.5	500	50	15
2SA1020	TO-92MOD	PNP	900	2000	50	50	5	70	240	2	500	0.5	1000	50	100
2SA1145	TO-92MOD	PNP	800	50	150	150	5	80	240	5	10	1	10	1	200
2SA1160	TO-92MOD	PNP	900	2000	20	10	6	140	600	1	500	0.5	2000	50	140
2SA1283	TO-92MOD	PNP	900	1000	60	60	6	55	300	4	100	0.3	500	25	50
2SA1371	TO-92MOD	PNP	1000	100	300	300	5	40	320	10	10	0.6	20	2	100
2SA817A	TO-92MOD	PNP	800	400	80	80	5	70	240	2	50	0.4	200	20	100
2SA965	TO-92MOD	PNP	900	800	120	120	5	80	240	5	100	1	500	50	120
2SA966	TO-92MOD	PNP	900	1500	30	30	5	100	320	2	500	2	1500	30	120
2SB560	TO-92MOD	PNP	900	700	100	80	5	60	560	5	50	0.8	500	50	100
2SB647	TO-92MOD	PNP	900	1000	120	80	5	60	320	5	150	1	500	50	140
2SB647A	TO-92MOD	PNP	900	1000	120	100	5	60	200	5	150	1	500	50	140
2SB740	TO-92MOD	PNP	900	1000	70	50	6	100	320	2	100	0.6	1000	100	150
2SB764	TO-92MOD	PNP	900	1000	60	50	5	60	320	2	50	0.7	500	50	150
2SB892	TO-92MOD	PNP	1000	2000	60	50	6	100	560	2	100	0.4	1000	50	150
2SB927	TO-92MOD	PNP	1000	2500	30	25	6	100	560	2	100	0.6	1500	75	150
2SB985	TO-92MOD	PNP	900	3000	60	50	6	100	560	2	100	0.7	2000	100	150
2SC1383	TO-92MOD	NPN	1000	1000	30	25	5	85	340	10	500	0.4	500	50	200
2SC1384	TO-92MOD	NPN	1000	1000	60	50	5	85	340	10	500	0.4	500	50	200
2SC1627A	TO-92MOD	NPN	800	400	80	80	5	70	240	2	50	0.4	200	20	100
2SC2060	TO-92MOD	NPN	750	1000	40	32	5	80	400	3	100	0.4	500	50	50
2SC2229	TO-92MOD	NPN	800	50	200	150	5	70	240	5	10	0.5	10	1	80
2SC2230	TO-92MOD	NPN	800	100	200	160	5	120	400	10	10	0.5	50	5	50
2SC2235	TO-92MOD	NPN	900	800	120	120	5	80	240	5	100	1	500	50	120
2SC2236	TO-92MOD	NPN	900	1500	30	30	5	100	320	2	500	2	1500	30	120
2SC2383	TO-92MOD	NPN	900	1000	160	160	6	60	320	5	200	1	500	50	20
2SC2482	TO-92MOD	NPN	900	100	300	300	7	30	150	10	20	1	10	1	50
2SC2500	TO-92MOD	NPN	900	2000	30	10	6	140	600	1	500	0.5	2000	50	150
2SC2655	TO-92MOD	NPN	900	2000	50	50	5	70	240	2	500	0.5	1000	50	100
2SC2703	TO-92MOD	NPN	900	1000	30	30	5	100	320	2	100	0.5	800	80	150
2SC3243	TO-92MOD	NPN	900	1000	60	60	6	55	300	4	100	0.3	500	25	120
2SD1247	TO-92MOD	NPN	1000	2500	30	25	6	100	560	2	100	0.4	1500	75	150
2SD400	TO-92MOD	NPN	900	1000	25	25	5	60	560	2	50	0.3	500	50	180
2SD468	TO-92MOD	NPN	900	1000	25	20	5	85	240	2	500	0.5	800	80	190
2SD667	TO-92MOD	NPN	900	1000	120	80	5	60	320	5	150	1	500	50	140
2SD667A	TO-92MOD	NPN	900	1000	120	100	5	60	320	5	150	1	500	50	140
2SD789	TO-92MOD	NPN	900	1000	100	50	6	100	800	2	100	0.3	1000	100	100
3CG751	TO-92MOD	PNP	900	1500	30	30	5	100	400	2	500	2	1500	30	50
BD034	TO-92MOD	PNP	900	2500	110	95	7	100	560	2	100	0.5	2000	200	3
KSA910	TO-92MOD	PNP	800	50	150	150	5	40	240	5	10	0.8	10	1	100
KSA928A	TO-92MOD	PNP	1000	2000	30	30	5	100	320	2	500	2	1500	30	120
KSA931	TO-92MOD	PNP	1000	700	80	60	8	40	320	2	50	0.7	500	50	100
KSC2316	TO-92MOD	NPN	900	800	120	120	5	80	240	5	100	1	500	50	120
KSC2328A	TO-92MOD	NPN	1000	2000	30	30	5	100	320	2	500	2	1500	30	120
KSC2330	TO-92MOD	NPN	1000	100	300	300	7	40	240	10	20	0.5	10	1	50
KSC2331	TO-92MOD	NPN	1000	700	80	60	8	40	240	2	50	0.7	500	50	30
KTA1281	TO-92MOD	PNP	1000	2000	50	50	5	70	240	2	500	0.5	1000	50	100
2SB1658	TO-126	PNP	1000	5000	30	30	6	150	600	2	1000	0.5	4000	200	95
2SB649	TO-126	PNP	1000	1500	180	120	5	60	320	5	150	1	500	50	140
2SB649A	TO-126	PNP	1000	1500	180	160	5	60	200	5	150	1	500	50	140
2SB776	TO-126	PNP	1000	3000	50	50	5	100	400	2	1000	0.5	2000	200	80
2SC1162	TO-126	NPN	1000	2500	35	35	5	60	320	2	500	1	2000	200	180
2SC2314	TO-126	NPN	750	1000	75	45	5	60	320	5	500	0.6	500	50	180
2SC2688	TO-126	NPN	1250	200	300	300	5	40	250	10	10	0.5	50	5	50
2SD2136	TO-126	NPN	1250	3000	60	60	6	40	250	4	1000	1.2	3000	375	30
2SD2583	TO-126	NPN	1000	5000	30	30	6	150	600	2	1000	0.5	4000	200	120
2SD669	TO-126	NPN	1000	1500	180	120	5	60	320	5	150	1	500	50	140
2SD669A	TO-126	NPN	1000	1500	180	160	5	60	200	5	150	1	500	50	140
2SD669AL	TO-126	NPN	1000	1000	200	170	6.5	100	320	5	150	0.9	500	50	140
2SD886	TO-126	NPN	1000	3000	50	50	5	100	400	2	1000	0.5	2000	200	80
3CA772	TO-126	PNP	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
3CA8772	TO-126	PNP	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
3DA882	TO-126	NPN	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
B772	TO-126	PNP	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
BD034	TO-126	PNP	1250	2500	110	95	7	100	560	2	100	0.5	2000	200	3
BD135	TO-126	NPN	1250	1500	45	45	5	40	250	2	150	0.5	500	50	190
BD136	TO-126	PNP	1250	1500	45	45	5	40	250	2	150	0.5	500	50
BD137	TO-126	NPN	1250	1500	60	60	5	40	250	2	150	0.5	500	50	190
BD138	TO-126	PNP	1250	1500	60	60	5	40	250	2	150	0.5	500	50
BD139	TO-126	NPN	1250	1500	80	80	5	40	250	2	150	0.5	500	50	190
BD140	TO-126	PNP	1250	1500	80	80	5	40	250	2	150	0.5	500	50
BD233	TO-126	NPN	1250	2000	45	45	5	40		2	150	0.6	1000	100	3
BD234	TO-126	PNP	1250	2000	45	45	5	40		2	150	0.6	1000	100	3
BD235	TO-126	NPN	1250	2000	60	60	5	40		2	150	0.6	1000	100	3
BD236	TO-126	PNP	1250	2000	60	60	5	40		2	150	0.6	1000	100	3
BD237	TO-126	NPN	1250	2000	100	80	5	40		2	150	0.6	1000	100	3
BD238	TO-126	PNP	1250	2000	100	80	5	40		2	150	0.6	1000	100	3
BD433	TO-126	NPN	1250	4000	22	22	5	85	375	1	500	0.5	2000	200	3
BD434	TO-126	PNP	1250	4000	22	22	5	85	375	1	500	0.5	2000	200	3
BD435	TO-126	NPN	1250	4000	32	32	5	85	375	1	500	0.5	2000	200	3
BD436	TO-126	PNP	1250	4000	32	32	5	85	375	1	500	0.5	2000	200	3
BD437	TO-126	NPN	1250	4000	45	45	5	85	375	1	500	0.6	2000	200	3
BD438	TO-126	PNP	1250	4000	45	45	5	85	375	1	500	0.7	3000	300	3
BD439	TO-126	NPN	1250	4000	60	60	5	40	475	1	500	0.8	3000	300	3
BD440	TO-126	PNP	1250	4000	60	60	5	40	475	1	500	0.8	3000	300	3
BD441	TO-126	NPN	1250	4000	80	80	5	40	475	1	500	0.8	3000	300	3
BD442	TO-126	PNP	1250	4000	80	80	5	40	475	1	500	0.8	3000	300	3
D882	TO-126	NPN	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	90
KSA1220	TO-126	PNP	1250	1200	120	120	5	60	320	5	300	0.7	1000	200	175
KSA1220A	TO-126	PNP	1250	1200	160	160	5	60	320	5	300	0.7	1000	200	175
KSB1151	TO-126	PNP	1250	5000	60	60	7	100	400	1	2000	0.3	2000	200
KSC2690	TO-126	NPN	1250	1200	120	120	5	60	320	5	300	0.7	1000	200	155
KSC2690A	TO-126	NPN	1250	1200	160	160	5	60	320	5	300	0.7	1000	200	155
KSD1691	TO-126	NPN	1300	5000	60	60	7	100	400	1	2000	0.3	2000	200
KSD1692	TO-126	NPN	1250	3000	150	100	8	2K	20K	2	1500	1.2	1500	1.5
MJE170	TO-126	PNP	1500	3000	60	40	7	50	250	1	100	1.7	3000	600	50
MJE171	TO-126	PNP	1500	3000	80	60	7	50	250	1	100	1.7	3000	600	50
MJE172	TO-126	PNP	1500	3000	100	80	7	50	250	1	100	1.7	3000	600	50
2SA1357	TO-126C	PNP	1500	5000	35	20	8	100	320	2	500	1	4000	100	170
2SA1627	TO-126C	PNP	1250	1000	600	600	7	30	120	5	100	0.5	300	60	10
2SB649	TO-126C	PNP	1000	1500	180	120	5	60	320	5	150	1	500	50	140
2SB649A	TO-126C	PNP	1000	1500	180	160	5	60	200	5	150	1	500	50	140
2SB776	TO-126C	PNP	1000	3000	50	50	5	100	400	2	1000	0.5	2000	200	80
2SC1162	TO-126C	NPN	1000	2500	35	35	5	60	320	2	500	1	2000	200	180
2SC3420	TO-126C	NPN	1500	5000	50	20	8	140	600	2	500	1	4000	100	100
2SC3421	TO-126C	NPN	1250	1000	120	120	5	80	240	5	100	1	500	50	120
2SC3807	TO-126C	NPN	1200	2000	30	25	15	800	3200	5	500	0.5	1000	20	260
2SD2136	TO-126C	NPN	1250	3000	60	60	6	40	250	4	1000	1.2	3000	375	30
2SD668A	TO-126C	NPN	1000	50	180	160	5	60	200	5	10	2	30	3	140
2SD669	TO-126C	NPN	1000	1500	180	120	5	60	320	5	150	1	500	50	140
2SD669A	TO-126C	NPN	1000	1500	180	160	5	60	200	5	150	1	500	50	140
2SD794	TO-126C	NPN	1000	3000	70	45	5	60	320	5	500	2	1500	150	60
2SD794A	TO-126C	NPN	1000	3000	70	60	5	60	320	5	500	2	1500	150	60
2SD886	TO-126C	NPN	1000	3000	50	50	5	100	400	2	1000	0.5	2000	200	80
B772	TO-126C	PNP	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
BD435	TO-126C	NPN	1250	4000	32	32	5	85	375	1	500	0.5	2000	200	3
D882	TO-126C	NPN	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
KSD1691	TO-126C	NPN	1300	5000	60	60	7	100	400	1	2000	1.2	2000	200
BD436	TO-126C	PNP	1250	4000	32	32	5	85	375	1	500	0.5	2000	200	3
2SA1012	TO-251/252	PNP	1250	5000	60	50	5	70	240	1	1000	0.4	3000	150	60
2SA1225	TO-251/252	PNP	1000	1500	160	160	5	70	240	5	100	1.5	500	50	100
2SA1242	TO-251/252	PNP	1000	5000	35	20	8	100	320	2	500	1	4000	100	170
2SA1615	TO-251/252	PNP	1000	10000	30	20	10	200	600	2	500	0.25	4000	50	180
2SA1700	TO-251/252	PNP	1000	200	400	400	5	60	200	10	50	0.8	50	5	70
2SB1182	TO-251/252	PNP	1500	2000	40	32	5	82	390	3	500	0.8	2000	200	100
2SB1184	TO-251/252	PNP	1000	3000	60	50	5	82	390	3	500	1	2000	200	70
2SB1202	TO-251/252	PNP	1000	3000	60	50	6	100	560	2	100	0.7	2000	100	150
2SB1261(TO-252)	TO-251/252	PNP	1000	3000	60	60	7	100	400	2	600	0.3	1500	150	50
2SB1261-Z(TO-251)	TO-251/252	PNP	1000	3000	60	60	7	100	400	2	600	0.3	1500	150	50
2SB1412	TO-251/252	PNP	1000	5000	30	20	6	82	390	2	500	1	4000	100	120
2SC2983	TO-251/252	NPN	1000	1500	160	160	5	70	240	5	100	1.5	500	50	100
2SC3303	TO-251/252	NPN	1000	5000	100	80	7	70	240	1	1000	0.4	3000	150	20
2SC4003	TO-251/252	NPN	1000	200	400	400	5	60	200	10	50	0.6	50	5	70
2SD1758	TO-251/252	NPN	1200	2000	40	32	5	82	390	3	500	0.8	2000	200	100
2SD1760	TO-251/252	NPN	1500	3000	60	50	5	82	390	3	500	1	2000	200	90
2SD1802	TO-251/252	NPN	1000	3000	60	50	6	100	560	2	100	0.5	2000	100	150
2SD1815	TO-251/252	NPN	1000	3000	120	100	6	70	400	5	500	0.4	1500	150	180
2SD1899(TO-252)	TO-251/252	NPN	1000	3000	60	60	7	100	400	2	600	0.25	1500	150	120
2SD1899-Z(TO-251)	TO-251/252	NPN	1000	3000	60	60	7	100	400	2	600	0.25	1500	150	120
2SD2118	TO-251/252	NPN	1000	5000	50	20	6	120	390	2	500	1	4000	100	150
3CA753	TO-251/252	PNP	1200	2000	40	30	5	100	400	2	500	2	1500	30	120
3DA752	TO-251/252	NPN	1200	2000	40	30	5	100	400	2	500	2	1500	30	120
B772M(TO-251)	TO-251/252	PNP	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
B772M(TO-252)	TO-251/252	PNP	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	50
D882M(TO-251)	TO-251/252	NPN	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	90
D882M(TO-252)	TO-251/252	NPN	1250	3000	40	30	6	60	400	2	1000	0.5	2000	200	90
KTA1042D	TO-251/252	PNP	1250	5000	100	100	5	70	240	5	1000	2	4000	400	30
MJD2955	TO-251/252	PNP	1250	10000	70	60	5	20	100	4	4000	8	10000	3300	2
MJD3055	TO-251/252	NPN	1250	10000	70	60	5	20	100	4	4000	8	10000	3300	2
MJD31C	TO-251/252	NPN	1250	3000	100	100	5	10	50	4	3000	1.2	3000	375	3
MJD32C	TO-251/252	PNP	1500	3000	100	100	5	15	75	4	3000	1.2	3000	375	3
MJD41C	TO-251/252	NPN	1250	6000	100	100	5	15	75	4	3000	1.5	6000	600	3
MJD42C	TO-251/252	PNP	1500	6000	100	100	5	15	75	4	3000	1.5	6000	600	3
2SA1012B	TO-251/252	PNP	1250	2000	50	50	5	82	270	2	500	0.35	1000	50	200
2SA1952	TO-251/252	PNP	1000	5000	100	60	5	120	270	2	1000	0.5	4000	200	80
2SA1012	TO-220-3L	PNP	2000	5000	60	50	5	70	240	1	1000	0.4	3000	150	60
2SA940	TO-220-3L	PNP	1500	1500	150	150	5	40	140	10	500	1.5	500	50	4
2SB1185	TO-220-3L	PNP	2000	3000	60	50	5	60	320	3	500	1	2000	200	70
2SB1274	TO-220-3L	PNP	2000	3000	60	60	6	70	280	5	500	1	2000	200	100
2SB1375	TO-220-3L	PNP	2000	3000	60	60	7	100	320	5	500	1.5	2000	200	9
2SB507	TO-220-3L	PNP	1750	3000	60	60	5	40	320	2	1000	1	2000	200	5
2SB834	TO-220-3L	PNP	1500	3000	60	60	7	60	200	5	500	1	3000	300	9
2SB857	TO-220-3L	PNP	2000	4000	70	50	5	60	320	4	1000	1	2000	200	15
2SB861	TO-220-3L	PNP	1800	2000	200	150	6	60	200	4	50	3	500	50
2SC2073	TO-220-3L	NPN	1500	1500	150	150	5	40	140	10	500	1.5	500	50	4
2SC4544	TO-220-3L	NPN	2000	100	300	300	7	30	200	10	20	1	10	1	70
2SD1762	TO-220-3L	NPN	2000	3000	60	50	5	60	320	3	500	1	2000	200	90
2SD2012	TO-220-3L	NPN	2000	3000	60	60	7	100	320	5	500	1	2000	200	3
2SD2061	TO-220-3L	NPN	2000	3000	80	60	5	100	320	5	500	1	2000	200	8
2SD2137	TO-220-3L	NPN	2000	3000	60	60	6	70	320	4	1000	1.2	3000	375	30
2SD2137A	TO-220-3L	NPN	2000	3000	80	80	6	70	320	4	1000	1.2	3000	375	30
2SD313	TO-220-3L	NPN	1750	3000	60	60	5	40	320	2	1000	1	2000	200	8
2SD880	TO-220-3L	NPN	1500	3000	60	60	7	60	300	5	500	1	3000	300	3
KTA1276	TO-220-3L	PNP	2000	3000	30	30	5	70	240	2	500	0.8	2000	200	100
KTA968A	TO-220-3L	PNP	2000	1500	180	180	5	70	240	5	100	1.5	500	50	100
KTB1366	TO-220-3L	PNP	2000	3000	60	60	7	60	200	5	500	1	2000	200	9
KTC2026	TO-220-3L	NPN	2000	3000	60	60	7	100	300	5	500	1	2000	200	30
KTC3229	TO-220-3L	NPN	2000	100	300	300	5	30	200	10	20	1	10	1	75
KTD1351	TO-220-3L	NPN	2000	3000	60	60	7	60	300	5	500	1	2000	200	3
KTD2058	TO-220-3L	NPN	2000	3000	60	60	7	60	200	5	500	1	2000	200	3
MJE2955	TO-220-3L	PNP	2000	10000	70	60	5	20	100	4	4000	8	10000	3300	2
MJE3055	TO-220-3L	NPN	2000	10000	70	60	5	20	100	4	4000	8	10000	3300	2
TIP31	TO-220-3L	NPN	2000	3000	40	40	5	15	75	4	3000	1.2	3000	375	3
TIP31C	TO-220-3L	NPN	2000	3000	100	100	5	15	75	4	3000	1.2	3000	375	3
TIP32	TO-220-3L	PNP	2000	3000	40	40	5	15	75	4	3000	1.2	3000	375	3
TIP32C	TO-220-3L	PNP	2000	3000	100	100	5	15	75	4	3000	1.2	3000	375	3
TIP41	TO-220-3L	NPN	2000	6000	40	40	5	15	75	4	3000	1.5	6000	600	3
TIP41C	TO-220-3L	NPN	2000	6000	100	100	5	15	75	4	3000	1.5	6000	600	3
TIP42	TO-220-3L	PNP	2000	6000	40	40	5	15	75	4	3000	1.5	6000	600	3
TIP42C	TO-220-3L	PNP	2000	6000	100	100	5	15	75	4	3000	1.5	6000	600	3
2SD1138	TO-220-3L	NPN	1800	2000	200	150	6	60	200	4	50	3	500	50
BU406	TO-220-3L	NPN	2000	7000	400	200	6	50	100	5	1000	1	5000	500	10
2SA2050	TO-220F	PNP	1500	1500	180	160	6	60	240	5	200	1	500	50	50
2SB1370	TO-220F	PNP	2000	3000	60	60	5	100	320	5	500	1.5	2000	200	15
2SB834	TO-220F	PNP	1500	3000	60	60	7	60	200	5	500	1	3000	300	5
2SB946	TO-220F	PNP	2000	7000	130	80	7	60	260	2	3000	0.5	5000	250	30
2SC5171	TO-220F	NPN	2000	2000	180	180	5	100	320	5	100	1	1000	100	200
2SD1271A	TO-220F	NPN	2000	7000	150	100	7	60	260	2	3000	0.5	5000	250	30
2SD1499	TO-220F	NPN	2000	5000	100	100	5	60	200	5	1000	2	3000	300	20
2SD1761	TO-220F	NPN	2000	3000	80	60	5	60	320	5	500	1	2000	200	8
2SD2012	TO-220F	NPN	2000	3000	60	60	7	100	320	5	500	1	2000	200	3
2SD2061	TO-220F	NPN	2000	3000	80	60	5	100	320	5	500	1	2000	200	8
2SD2137	TO-220F	NPN	2000	3000	60	60	6	70	320	4	1000	1.2	3000	375	30
3CA1837	TO-220F	PNP	1500	1000	230	230	5	100	320	5	100	1.5	500	50	30
3CA2050	TO-220F	PNP	1500	1500	180	160	6	60	240	5	200	1	500	50	50
3DA4793	TO-220F	NPN	1500	1000	230	230	5	100	320	5	100	1.5	500	50	30
3DA5371	TO-220F	NPN	1500	1500	180	160	6	60	240	5	200	1	500	50	50
3DD3853	TO-220F	NPN	2000	3000	60	60	7	60	300	5	500	1	3000	300	5
KSA614F	TO-220F	PNP	2000	3000	80	55	5	40	240	5	500	0.5	1000	100
KSD1408	TO-220F	NPN	2000	4000	80	80	5	40	240	5	500	1.5	3000	300	8
KTA1659	TO-220F	PNP	2000	1500	160	160	5	70	240	5	100	1.5	500	50	100
KTA1659A	TO-220F	PNP	2000	1500	180	180	5	70	240	5	100	1.5	500	50	100
KTB1366	TO-220F	PNP	2000	3000	60	60	7	60	200	5	500	1	2000	200	9
KTB1367	TO-220F	PNP	2000	5000	100	100	5	40	240	5	1000	2	4000	400	5
KTC4369	TO-220F	NPN	2000	3000	30	30	5	70	240	2	500	0.8	2000	200	100
KTC4370A	TO-220F	NPN	2000	1500	180	180	5	70	240	5	100	1.5	500	50	100
KTD2058	TO-220F	NPN	2000	3000	60	60	7	60	200	5	500	1	2000	200	3
KTD2061	TO-220F	NPN	2000	2000	200	180	5	70	240	10	400	1	500	50	100
2SB1568	TO-220F	PNP	2000	4000	80	80	7	1000	10000	4	3000	1.5	3000	12	15
2SD2396	TO-220F	NPN	2000	3000	80	60	6	400	2000	4	500	0.8	2000	50	40
2SA1615	TO-263-2L	PNP	1000	10000	30	20	10	200	600	2	500	0.25	4	0.05	180
2SD2012	TO-263-2L	NPN	2000	30000	60	60	7	100	320	5	500	1	2	0.2	3

R/L/C...

Transistor

热门推荐

About us

Components

Customizable

Services
