Disc antenna
Telecom:4G/NB-IoT/GSM
Wifi:2.4G/5.8G
Technical Specification:
| Product Name: | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna |
| Part Number: | BMHX-XP5G-24330 | BMHX-XP4G-16060 | BMHX-XP4G-22530 | BMHX-XP4G-31730 | BMHX-XPNB-9830 | BMHX-XP433-19060 | BMHX-XPNB-16030 | BMHX-XP433-17330 | BMHX-XP25-15030 | BMHX-XP315-22530 |
| Type: | Telecom,Wifi,Lora | Telecom,Wifi,Lora | Telecom,Wifi,Lora | Telecom,Wifi,Lora | Telecom,Wifi,Lora | Telecom,Wifi,Lora | Telecom,Wifi,Lora | Telecom,Wifi,Lora | Telecom,Wifi,Lora | Telecom,Wifi,Lora |
| Application: | Cabinet, Help desk, Vehicle | Cabinet, Help desk, Vehicle | Cabinet, Help desk, Vehicle | Cabinet, Help desk, Vehicle | Cabinet, Help desk, Vehicle | Cabinet, Help desk, Vehicle | Cabinet, Help desk, Vehicle | Cabinet, Help desk, Vehicle | Cabinet, Help desk, Vehicle | Cabinet, Help desk, Vehicle |
| Supported Bands: | Telecom:5G/4G/NB-IoT/GSM | Telecom:4G/NB-IoT/GSM Wifi:2.4G/5.8G | Telecom:4G/NB-IoT/GSM Wifi:2.4G/5.8G | Telecom:4G/NB-IoT/GSM Wifi:2.4G/5.8G | NB-IoT/GSM | Lora:433M | NB-IoT/GSM | Lora:433M | Wifi:2.4G/5.8G | Lora:315M |
| Product Type: | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna | Disc antenna |
| Effeciency | 40-72% | 40-70% | 40-56% | 40-75% | 40-52% | 40-65% | 40-67% | 40-65% | 40-60% | 40-58% |
| LNA Gain: | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| Gain: | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| Connector: | SMA,customizable | SMA,customizable | SMA,customizable | SMA,customizable | SMA,customizable | SMA,customizable | SMA,customizable | SMA,customizable | SMA,customizable | SMA,customizable |
| Antenna Axis Rate: | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| Center Phase Tol: | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| Output VSWR: | ≤1.8 | ≤1.8 | ≤1.8 | ≤1.8 | ≤1.8 | ≤1.8 | ≤1.8 | ≤1.8 | ≤1.8 | ≤1.8 |
| Direction of Polarization: | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| Port Impedance: | 50Ω | 50Ω | 50Ω | 50Ω | 50Ω | 50Ω | 50Ω | 50Ω | 50Ω | 50Ω |
| Water Proof: | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| Size: | 243*30mm | 160*60mm | 225*30mm | 317*30mm | 98*30mm | 190*60mm | 160*30mm | 173*30mm | 150*30mm | 225*30mm |
